SAPPHIRE PULSE Radeon RX 9050 8GB gegen AMD Radeon RX 7400. Specifications

Vergleich der grundlegenden technischen Daten von Grafikkarten SAPPHIRE PULSE Radeon RX 9050 8GB und AMD Radeon RX 7400, Chip, Informationsverarbeitungseinheiten.

• Based on
  AMD Radeon RX 9050 AMD Radeon RX 7400
• Board Manufacturer
  Sapphire -
• Board Model
  SAPPHIRE PULSE Radeon RX 9050 8GB -
• Board SKU
  11363-01 -
• Compute Units
  16 CUs (3rd Gen RT + 2nd Gen AI Accelerators) 28
• Stream Processors
  1024 -
• AI Accelerators
  - 56
• Execution Units
  - 28
• Ray Accelerators
  - 28
• Render Output Einheiten
  - 64
• Shader
  - 1792

Video memory capacity, type, bus width and bandwidth describe different properties. These values alone do not determine graphics performance.

• Memory Bus
  128 bit 128 bit
• Memory Data Rate
  18 Gbps Effective 10.8 Gbps
• Speichergröße
  8 GB 8 GB
• Speicher Typ
  GDDR6 GDDR6
• Infinity Cache
  - 32 MB
• Memory Bandwidth
  - 173 GB/s

Published GPU clock frequencies describe different operating modes. Clock speed alone does not determine graphics performance.

• Maximale Frequenz
  Up to 2760 MHz -
• Game Clock
  Up to 2260 MHz -

Graphics card power limits and recommended system power supply describe different specifications.

• System Power Supply
  650 W (System power requirement) 450 W (System power requirement)
• Total Board Power
  100W Typical Board Power -
• GPU Power
  - Up to 43 W
• Typical Board Power
  - 55 W

Konnektivität und Verbindungen.

• DisplayPort Ports
  1 × DisplayPort 2.1a -
• HDMI-Ports
  2 × HDMI 2.1b -
• PCIe Interface
  PCIe 5.0 x16 -
• DisplayPort Version
  - 2.1
• HDMI Version
  - 2.1

Der Unterschied in Größe, Gewicht und Steckplatz der verglichenen Geräte

• Form Factor
  2 slot, ATX Dimension: 200(L) X 109.25(W) X 40.6(H)mm -

Vergleich von Schnittstellen und Freigabeterminen für GPU AMD Radeon RX 7400 und SAPPHIRE PULSE Radeon RX 9050 8GB.

• Official source
  https://www.sapphiretech.com/en/consumer/pulse-radeon-rx-9050-8g-gddr6 https://www.amd.com/en/products/graphics/desktops/radeon/7000-series/amd-radeon-rx-7400.html
• Verified on
  2026-09-30 2026-09-30
