Palit GeForce RTX 5060 Dual 8GB gegen AMD Radeon RX 7900 GRE. Specifications

Vergleich der grundlegenden technischen Daten von Grafikkarten Palit GeForce RTX 5060 Dual 8GB und AMD Radeon RX 7900 GRE, Chip, Informationsverarbeitungseinheiten.

• Based on
  NVIDIA GeForce RTX 5060 AMD Radeon RX 7900 GRE
• Board Manufacturer
  Palit -
• Board Model
  Palit GeForce RTX 5060 Dual 8GB -
• Board SKU
  NE75060019P1-GB2063D -
• CUDA Cores
  3840 -
• GPU Chip
  NVIDIA GeForce RTX 5060 -
• AI Accelerators
  - 160
• Architektur
  - RDNA 3
• Compute Units
  - 80
• Execution Units
  - 80
• Ray Accelerators
  - 80
• Shader
  - 5120

Video memory capacity, type, bus width and bandwidth describe different properties. These values alone do not determine graphics performance.

• Memory Bandwidth
  448 GB/s 576 GB/s
• Memory Bus
  128 bit 256 bit
• Memory Data Rate
  28 Gbps 18 Gbps
• Speichergröße
  8 GB 16 GB
• Speicher Typ
  GDDR7 GDDR6
• Infinity Cache
  - 64 MB

Published GPU clock frequencies describe different operating modes. Clock speed alone does not determine graphics performance.

• Maximale Frequenz
  2497 MHz 2245 MHz
• Graphics Clock
  2280 MHz -
• Game Clock
  - 1880 MHz

Graphics card power limits and recommended system power supply describe different specifications.

• System Power Supply
  550 W (PSU recommendation) -
• Total Board Power
  145 W -
• TDP
  - 260 W
• Typical Board Power
  - 260 W

Konnektivität und Verbindungen.

• DisplayPort Version
  DP2.1b x 3 2.1
• HDMI Version
  HDMI 2.1b 2.1
• PCIe Interface
  PCI-E 5.0 -
• Power Connectors
  8-pin x 1 2x8-Pin

Integrierte Unterstützung für Video- und Bildkompressionsstandards.

• AV1
  - Decode / Encode

Der Unterschied in Größe, Gewicht und Steckplatz der verglichenen Geräte

• Abmessungen
  262.1 x 126.3 x 40.1 mm -
• Slot Size
  2 Slot -

Vergleich von Schnittstellen und Freigabeterminen für GPU AMD Radeon RX 7900 GRE und Palit GeForce RTX 5060 Dual 8GB.

• Official source
  https://www.palit.com/palit/vgapro.php?id=5575&lang=en&pn=NE75060019P1-GB2063D&tab=sp https://www.amd.com/en/products/graphics/desktops/radeon/7000-series/amd-radeon-rx-7900-gre.html
• Verified on
  2026-09-30 2026-09-30
• Architecture source
  - https://www.amd.com/content/dam/amd/en/documents/partner-hub/ryzen/amd-consumer-pocket-guide-ryzen-radeon-july-2024.pdf
• Datum der Veröffentlichung
  - 2023-07-27
• Verification scope
  - Explicit manufacturer fields refreshed; other original historical fields retained, not all reverified. Partial composite conflicts are preserved.

• FP32 (theoretical)
  - 46 TFLOPS
