Graphics card ASUS ROG Strix GeForce RTX 2060 SUPER EVO Advanced Edition, specifications and benchmarks

Key features of the graphics card ASUS ROG Strix GeForce RTX 2060 SUPER EVO Advanced Edition.

• Based on
  NVIDIA GeForce RTX 2060 SUPER
• GPU Chip
  TU106
• Execution units
  34
• Shader
  2176
• Render Output Units
  64
• Texture Units
  136

The characteristics of the video memory on board the graphics card. The higher the better.

• Memory Size
  8 GB
• Memory Type
  GDDR6
• Memory Speed
  1.75 GHz
• Memory Bandwith
  448 GB/s
• Memory Interface
  256 bit

Video card clock speed and overclocking potential ASUS ROG Strix GeForce RTX 2060 SUPER EVO Advanced Edition.

• Base Clock
  1.470 GHz
• Boost Clock
  1.710 GHz+ 4 %
• Avg (Game) Clock
  1.680 GHz
• Overclocking
  Yes

Connectors, the number of thermal watts emitted in normal mode and at overclocking.

• TDP
  175 W
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  1 x 6-Pin, 1 x 8-Pin

Cooling system parameters, connectors and fan types ASUS ROG Strix GeForce RTX 2060 SUPER EVO Advanced Edition.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Fan 1
  3 x 90 mm
• Noise (Idle)
  0 dB / Silent
• Fan 2
  --
• Noise (Load)
  --

Connectivity and connections.

• Max. Displays
  4
• HDCP-Version
  2.2
• HDMI Ports
  2x HDMI v2.0b
• DP Ports
  2x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  1

Hardware capabilities and maintaining the API.

• Max. resolution
  7680x4320
• DirectX
  12_2
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  ASUS Aura Sync

Built-in support for video and image compression standards.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  No

• Length
  301 mm
• Height
  131 mm
• Width
  49 mm
• Width (Slots)
  3 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 3.0 x 16
• Release date
  Q4/2019
• Release price
  --
• Structure size
  12 nm
• Part-no
  ROG-STRIX-RTX2060S-A8G-EVO-GAMING
• Documents
  data sheet

Common positions ASUS ROG Strix GeForce RTX 2060 SUPER EVO Advanced Edition GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  1895 place
• Battlefield 5
  1840 place
• Shadow of the Tomb Raider
  1549 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  1609 place
• Crypto-Mining Ergo Hashrate (MH/s)
  1306 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  1656 place
• 3DMark Benchmark
  1522 place
