ASRock Radeon RX 6950 XT OC Formula 16GB
Seleziona la scheda video 2
User rating
star star star star star
Rilasciato
Q2/2022
ASRock Radeon RX 6950 XT OC Formula 16GB

Scheda grafica ASRock Radeon RX 6950 XT OC Formula 16GB, specifiche e parametri di riferimento

51 posto nella classifica generale Schede grafiche (GPU)!
Una panoramica dettagliata della scheda video ASRock Radeon RX 6950 XT OC Formula 16GB, la cui data di produzione è iniziata in Q2/2022. Tutte le specifiche tecniche sono presentate qui, così come i risultati delle prestazioni sotto forma di stime da benchmark moderni. Frequenza di clock iniziale 2.143 GHz+ 11 %. La scheda video supporta GDDR6 e contiene 16 GB memoria video a bordo. Il TDP è 335 W. Si consiglia di confrontare la GPU con altri modelli presenti sul nostro sito web per determinare le prestazioni migliori.

Specifiche

Dati tecnici
GPU
  • Basato su
    AMD Radeon RX 6950 XT
  • Execution Units
    80
  • Chip GPU
    Navi 21 KXTX
  • Unità di uscita del rendering
    128
  • Shader
    5120
  • Unità di texture
    320
Memoria
  • Memory Bandwidth
    576 GB/s
  • Memory Bus
    256 bit
  • Memory Clock
    2250 MHz
  • Memory Data Rate
    18 Gbps
  • Dimensione della memoria
    16 GB
  • Tipo di memoria
    GDDR6
Frequenza di clock
  • Frequenza di base
    2143 MHz + 11%
  • Frequenza massima
    2495 MHz + 7%
  • Game Clock
    2279 MHz + 8%
  • Overclock
    Sì
Consumo di energia
  • Maximum Junction Temperature
    —
  • TDP
    335 W
  • TDP (up)
    —
Raffreddamento
  • Cooler-Type
    Air cooling
  • Fan-Type
    Axial
  • Ventilatore 1
    3 x 100 mm
  • Ventilatore 2
    —
  • Noise (Idle)
    0 dB / Silent
  • Noise (Load)
    —
Connettività
  • DisplayPort Ports
    3 × DisplayPort 1.4a
  • Porte DVI
    —
  • HDCP Version
    2.3
  • Porte HDMI
    1 × HDMI 2.1
  • Max. Visualizzazioni
    4
  • PCIe Interface
    PCIe 4.0 x16
  • Power Connectors
    3 x 8-Pin
  • USB-C Ports
    —
  • VGA Ports
    —
Featureset
  • DirectX
    12_2
  • DLSS / FSR
    No
  • LED
    Addressable LED
  • Risoluzione massima
    7680 × 4320
  • Raytracing
    Sì
Codec video supportati
  • AV1
    Decode
  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode / Encode
  • VP9
    Decode / Encode
Dimensioni
  • Altezza
    137 mm
  • Lunghezza
    332 mm
  • Slot Size
    3 PCIe-Slots
  • Weight
    1784 g
  • Width
    61 mm
Dati aggiuntivi
  • Specifica
    data sheet
  • Launch Price (historical)
    —
  • Part Number
    RX6950XT OCF 16G
  • Process Technology
    7 nm
  • Data di rilascio
    Q2/2022
Posizioni in tutte le classifiche

Posizioni comuni ASRock Radeon RX 6950 XT OC Formula 16GB GPU in benchmark popolari, per un confronto con altri modelli.

  • FP32 Performance (Single-precision TFLOPS)
    349 place
  • 3DMark Benchmark
    41 place
  • Battlefield 5
    27 place
  • Shadow of the Tomb Raider
    188 place
  • Crypto-Mining Ethereum Hashrate (MH/s)
    707 place
  • Crypto-Mining Ergo Hashrate (MH/s)
    867 place
  • Crypto-Mining Ravencoin Hashrate (MH/s)
    839 place

Manufacturer versions

Board specifications and benchmark results are specific to each version.

All models based on this GPU

Benchmark (test)

Test di performance GPU

Confrontare i punteggi dei benchmark più diffusi ASRock Radeon RX 6950 XT OC Formula 16GB con altre schede grafiche per capire la reale velocità della GPU nell'elaborazione dei contenuti.

I test includono il lavoro con la virgola mobile, la creazione di modelli 3D, il mining di criptovalute.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archive: saved catalog source links. The original measurement method and test conditions have not been verified; current source pages may differ from the imported content. ASRock Radeon RX 6950 XT OC Formula 16GB

FP32 Performance (Single-precision TFLOPS)
Benchmark FP32 è un calcolo in virgola mobile a 32 bit per la GPU che è richiesto per il gioco 3D.

Higher values are better in this metric.

3DMark Benchmark
3DMark è progettato per i giocatori, gli overclocker e i costruttori di sistemi che vogliono ottenere il massimo dal loro hardware.

Higher values are better in this metric.

Battlefield 5
Battlefield 5 è un gioco realistico, con un benchmark incorporato, molto adatto come test per le schede grafiche.

Higher values are better in this metric.

Shadow of the Tomb Raider
Shadow of the Tomb Raider ha un benchmark incorporato, basato sul motore Crystal Dynamics Foundation.

Higher values are better in this metric.

Crypto-Mining Ethereum Hashrate (MH/s)
Ethash è un algoritmo per il mining della criptovaluta Ethereum che sfrutta al massimo la GPU.

Higher values are better in this metric.

56 MH/s
ASRock Radeon RX 6950 XT OC Formula 16GB
58 MH/s
58 MH/s
58 MH/s
Crypto-Mining Ergo Hashrate (MH/s)
L'algoritmo Autolykos, su cui si basa la criptovaluta Ergo, permette non solo alle moderne GPU di essere utilizzate per il mining, ma anche alla passata generazione di GPU.

Higher values are better in this metric.

Crypto-Mining Ravencoin Hashrate (MH/s)
Hashrate mining della criptovaluta Ravencoin sull'algoritmo KawPoW è il più veloce sulle moderne schede video.

Higher values are better in this metric.

27 MH/s
ASRock Radeon RX 6950 XT OC Formula 16GB
28 MH/s
28 MH/s
28 MH/s

Sinonimi

Nearby models in the composite benchmark index.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted. Index 0–100: equal-weight mean of each score relative to the best saved score among models with both tests. Tests: Battlefield 5 + Shadow of the Tomb Raider. This index does not predict performance in every workload.

Recent models: test results with identified primary sources — Game frame rates

EVGA GeForce RTX 3090 FTW3 ULTRA GAMING EVGA GeForce RTX 3090 FTW3 ULTRA GAMING Vedi
EVGA GeForce RTX 3090 FTW3 ULTRA HYBRID GAMING EVGA GeForce RTX 3090 FTW3 ULTRA HYBRID GAMING Vedi
EVGA GeForce RTX 3090 FTW3 ULTRA HYDRO COPPER GAMING EVGA GeForce RTX 3090 FTW3 ULTRA HYDRO COPPER GAMING Vedi
Colorful iGame GeForce RTX 3090 Vulcan OC-V Colorful iGame GeForce RTX 3090 Vulcan OC-V Vedi
GIGABYTE AORUS GeForce RTX 3080 Ti Xtreme 12G GIGABYTE AORUS GeForce RTX 3080 Ti Xtreme 12G Vedi
ZOTAC Gaming GeForce RTX 3090 AMP Extreme Holo ZOTAC Gaming GeForce RTX 3090 AMP Extreme Holo Vedi
MSI GeForce RTX 3090 Suprim 24G MSI GeForce RTX 3090 Suprim 24G Vedi
KFA2 GeForce RTX 3090 HOF Premium KFA2 GeForce RTX 3090 HOF Premium Vedi

*

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.
