PowerColor Red Devil Radeon RX 6750 XT 12GB
Select video card 2
User rating
star star star star star
Released
Q2/2022
PowerColor Red Devil Radeon RX 6750 XT 12GB

Graphics card PowerColor Red Devil Radeon RX 6750 XT 12GB, specifications and benchmarks

649 place in the overall ranking Graphics Cards!
It is a detailed review of PowerColor Red Devil Radeon RX 6750 XT 12GB, the date of manufacture started in Q2/2022. Here are all specifications and the results of performance in the form of modern benchmark estimations. The base clock frequency is 2.200 GHz. The GPU supports GDDR6 with an 12 GB graphics memory. TDP is 250 W. We recommend comparing the GPU with other models on our website to determine the best performance.

Specifications

Technical data
GPU
  • Based on
    AMD Radeon RX 6750 XT
  • Execution Units
    40
  • GPU Chip
    Navi 22 KXT
  • Render Output Units
    64
  • Shader
    2560
  • Texture Units
    160
Memory
  • Memory Bandwidth
    432 GB/s
  • Memory Bus
    192 bit
  • Memory Clock
    2250 MHz
  • Memory Data Rate
    18 Gbps
  • Memory Size
    12 GB
  • Memory Type
    GDDR6
Clock Speeds
  • Base Clock
    2200 MHz
  • Boost Clock
    2713 MHz + 4%
  • Game Clock
    2633 MHz + 6%
  • Overclocking
    Yes
Thermal Design
  • Maximum Junction Temperature
    —
  • TDP
    250 W
  • TDP (up)
    —
Cooler & Fans
  • Cooler-Type
    Air cooling
  • Fan-Type
    Axial
  • Fan 1
    2 x 100 mm
  • Fan 2
    1 x 90 mm
  • Noise (Idle)
    0 dB / Silent
  • Noise (Load)
    —
Connectivity
  • DisplayPort Ports
    3 × DisplayPort 1.4a
  • DVI Ports
    —
  • HDCP Version
    2.3
  • HDMI Ports
    1 × HDMI 2.1
  • Max. Displays
    4
  • PCIe Interface
    PCIe 4.0 x16
  • Power Connectors
    2 x 8-Pin
  • USB-C Ports
    —
  • VGA Ports
    —
Featureset
  • DirectX
    12_2
  • DLSS / FSR
    No
  • LED
    Addressable LED
  • Max. resolution
    7680 × 4320
  • Raytracing
    Yes
Supported Video Codecs
  • AV1
    Decode
  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode / Encode
  • VP9
    Decode / Encode
Dimensions
  • Height
    130 mm
  • Length
    320 mm
  • Slot Size
    3 PCIe-Slots
  • Weight
    —
  • Width
    50 mm
Additional data
  • Documents
    data sheet
  • Launch Price (historical)
    —
  • Part Number
    AXRX 6750 XT 12GBD6-3DHE/OC
  • Process Technology
    7 nm
  • Release date
    Q2/2022
Positions in all rankings

Common positions PowerColor Red Devil Radeon RX 6750 XT 12GB GPU in popular benchmarks, for comparison with other models.

  • FP32 Performance (Single-precision TFLOPS)
    874 place
  • 3DMark Benchmark
    726 place
  • Battlefield 5
    648 place
  • Shadow of the Tomb Raider
    626 place
  • Crypto-Mining Ethereum Hashrate (MH/s)
    1432 place

Manufacturer versions

Board specifications and benchmark results are specific to each version.

All models based on this GPU

Benchmarks

Performance tests GPU

Compare the scores of popular benchmarks PowerColor Red Devil Radeon RX 6750 XT 12GB with other graphics cards to understand the real speed of the GPU when processing content.

Tests include working with floating point, creating 3D models, mining cryptocurrencies.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archive: saved catalog source links. The original measurement method and test conditions have not been verified; current source pages may differ from the imported content. PowerColor Red Devil Radeon RX 6750 XT 12GB

FP32 Performance (Single-precision TFLOPS)
Benchmark FP32 is a 32-bit floating point calculation for the GPU which is required for 3D gaming

Higher values are better in this metric.

13.89 TFLOPS
PowerColor Red Devil Radeon RX 6750 XT 12GB
13.97 TFLOPS
13.97 TFLOPS
13.97 TFLOPS
3DMark Benchmark
3DMark is designed for gamers, overclockers and system builders who want to get the most out of their hardware

Higher values are better in this metric.

12682
PowerColor Red Devil Radeon RX 6750 XT 12GB
13835
13835
13835
Battlefield 5
Battlefield 5 is a realistic game, with a built-in benchmark, very suitable as a test for graphics cards

Higher values are better in this metric.

Shadow of the Tomb Raider
Shadow of the Tomb Raider has a built-in benchmark, based on the Crystal Dynamics Foundation engine

Higher values are better in this metric.

52 fps
PowerColor Red Devil Radeon RX 6750 XT 12GB
53 fps
53 fps
53 fps
Crypto-Mining Ethereum Hashrate (MH/s)
Ethash is an algorithm for mining Ethereum cryptocurrency that makes the most of the GPU

Higher values are better in this metric.

Synonyms

Nearby models in the composite benchmark index.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted. Index 0–100: equal-weight mean of each score relative to the best saved score among models with both tests. Tests: Battlefield 5 + Shadow of the Tomb Raider. This index does not predict performance in every workload.

Recent models: test results with identified primary sources — Game frame rates

ASUS Dual GeForce RTX 3070 ASUS Dual GeForce RTX 3070 View
ASUS Dual GeForce RTX 3070 SI Edition ASUS Dual GeForce RTX 3070 SI Edition View
ASUS EKWB GeForce RTX 3070 ASUS EKWB GeForce RTX 3070 View
ASUS GeForce RTX 3070 Noctua Edition ASUS GeForce RTX 3070 Noctua Edition View
Palit GeForce RTX 3070 GamingPro OC V1 LHR Palit GeForce RTX 3070 GamingPro OC V1 LHR View
GIGABYTE GeForce RTX 3070 Eagle OC 8G (rev. 2.0) LHR GIGABYTE GeForce RTX 3070 Eagle OC 8G (rev. 2.0) LHR View
Gainward GeForce RTX 3070 Phoenix GS V1 LHR Gainward GeForce RTX 3070 Phoenix GS V1 LHR View
MSI GeForce RTX 3070 Gaming Trio Plus 8G LHR MSI GeForce RTX 3070 Gaming Trio Plus 8G LHR View

*

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.
