Graphics card GIGABYTE GeForce RTX 3060 Ti Vision OC 8G, specifications and benchmarks

Key features of the graphics card GIGABYTE GeForce RTX 3060 Ti Vision OC 8G.

• Based on
  NVIDIA GeForce RTX 3060 Ti
• GPU Chip
  GA104-200-A1
• Execution units
  38
• Shader
  4864
• Render Output Units
  80
• Texture Units
  152

The characteristics of the video memory on board the graphics card. The higher the better.

• Memory Size
  8 GB
• Memory Type
  GDDR6
• Memory Speed
  1.75 GHz
• Memory Bandwith
  448 GB/s
• Memory Interface
  256 bit

Video card clock speed and overclocking potential GIGABYTE GeForce RTX 3060 Ti Vision OC 8G.

• Base Clock
  1.410 GHz
• Boost Clock
  1.755 GHz-10 %
• Avg (Game) Clock
  1.665 GHz
• Overclocking
  Yes

Connectors, the number of thermal watts emitted in normal mode and at overclocking.

• TDP
  200 W
• TDP (up)
  240 W+ 9 %
• Tjunction max
  --
• PCIe-Power
  1 x 6-Pin, 1 x 8-Pin

Cooling system parameters, connectors and fan types GIGABYTE GeForce RTX 3060 Ti Vision OC 8G.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Fan 1
  3 x 80 mm
• Noise (Idle)
  0 dB / Silent
• Fan 2
  --
• Noise (Load)
  36 dB

Connectivity and connections.

• Max. Displays
  4
• HDCP-Version
  2.3
• HDMI Ports
  2x HDMI v2.1
• DP Ports
  2x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  --

Hardware capabilities and maintaining the API.

• Max. resolution
  7680x4320
• DirectX
  12_2
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  GIGABYTE RGB Fusion

Built-in support for video and image compression standards.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Length
  281 mm
• Height
  115 mm
• Width
  40 mm
• Width (Slots)
  2 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 4.0 x 16
• Release date
  Q4/2020
• Release price
  449 $
• Structure size
  8 nm
• Part-no
  GV-N306TVISION OC-8GD
• Documents
  data sheet

Common positions GIGABYTE GeForce RTX 3060 Ti Vision OC 8G GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  628 place
• Battlefield 5
  799 place
• Shadow of the Tomb Raider
  812 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  497 place
• Crypto-Mining Ergo Hashrate (MH/s)
  494 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  1345 place
• 3DMark Benchmark
  754 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  246 place
