Graphics card ASUS GeForce GT 1030 silent DDR4, specifications and benchmarks

Key features of the graphics card ASUS GeForce GT 1030 silent DDR4.

• Based on
  NVIDIA GeForce GT 1030 (DDR4)
• GPU Chip
  GP108-310-A1
• Execution units
  3
• Shader
  384
• Render Output Units
  16
• Texture Units
  24

The characteristics of the video memory on board the graphics card. The higher the better.

• Memory Size
  2 GB
• Memory Type
  DDR4
• Memory Speed
  1.05 GHz
• Memory Bandwith
  17 GB/s
• Memory Interface
  64 bit

Video card clock speed and overclocking potential ASUS GeForce GT 1030 silent DDR4.

• Base Clock
  1.151 GHz
• Boost Clock
  1.417 GHz+ 3 %
• Avg (Game) Clock
  1.379 GHz
• Overclocking
  Yes

Connectors, the number of thermal watts emitted in normal mode and at overclocking.

• TDP
  30 W+ 50 %
• TDP (up)
  --
• Tjunction max
  --

Cooling system parameters, connectors and fan types ASUS GeForce GT 1030 silent DDR4.

• Fan-Type
  --
• Cooler-Type
  Passive
• Fan 1
  --
• Noise (Idle)
  0 dB / Silent
• Fan 2
  --
• Noise (Load)
  0 dB

Connectivity and connections.

• Max. Displays
  3
• HDCP-Version
  2.2
• HDMI Ports
  --
• DP Ports
  --
• DVI Ports
  1
• VGA Ports
  --
• USB-C Ports
  --

Hardware capabilities and maintaining the API.

• Max. resolution
  4096x2160
• DirectX
  12_1
• Raytracing
  No
• DLSS / FSR
  No
• LED
  No LED lighting

Built-in support for video and image compression standards.

• h264
  Decode
• VP8
  No
• h265 / HEVC
  Decode
• VP9
  Decode
• AV1
  No

• Length
  173 mm
• Height
  69 mm
• Width
  40 mm
• Width (Slots)
  2 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 3.0 x 4
• Release date
  Q1/2018
• Release price
  --
• Structure size
  14 nm
• Part-no
  GT1030-SL-2GD4-BRK
• Documents
  data sheet

Common positions ASUS GeForce GT 1030 silent DDR4 GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  3102 place
• Battlefield 5
  2985 place
• Shadow of the Tomb Raider
  3029 place
