AMD Ryzen 5 7600X3D vs AMD Ryzen 3 PRO 8305GE. Specifications, performance, tests

Background information about the processors being compared, series, generation and market segment.

• Family
  Ryzen Ryzen PRO
• Form Factor
  Desktops / Boxed Processor Desktops
• Segment
  Desktop Desktop
• Series
  Ryzen 7000 Series Ryzen PRO 8000 Series

Core counts, threads, cache and clock modes describe the CPU configuration. Performance depends on the workload and comparable measured results.

• Base Frequency
  4.1 GHz 3.5 GHz
• CPU Cores
  6 4
• CPU Threads
  12 8
• Max. Boost Clock
  4.7 GHz 4.9 GHz

Internal Graphics does not affect the performance of the CPU, performs the work of the graphics card in its absence or on mobile devices.

• GPU Frequency
  2200 MHz 2600 MHz
• GPU name
  AMD Radeon Graphics AMD Radeon 740M
• Graphics Cores
  2 4

Types, channel quantity of RAM supported by AMD Ryzen 3 PRO 8305GE and AMD Ryzen 5 7600X3D. Depending on the motherboards, higher or lower memory frequencies may be supported.

• Memory channels
  2 2
• Memory type
  DDR5 DDR5
• PCIe
  PCIe 5.0 PCIe 4.0

Compare the TDP requirements of TDP AMD Ryzen 5 7600X3D and AMD Ryzen 3 PRO 8305GE Power specifications describe different manufacturer limits. TDP, base power and maximum turbo power are separate values; they do not establish measured system consumption.

• Default TDP
  65 W 35 W
• Maximum Operating Temperature
  89 °C 95 °C

Architecture, interfaces, additional instructions supported by AMD Ryzen 5 7600X3D and AMD Ryzen 3 PRO 8305GE, virtual machine technologies and process technology.

• Codename
  Raphael AM5 Phoenix
• L2-Cache
  6 MB 4 MB
• L3-Cache
  96 MB 8 MB
• Release date
  2024-09-05 2025-12-04
• Socket
  AM5 AM5
• Technology
  TSMC 5nm FinFET TSMC 4nm FinFET
