AMD Ryzen 7 8700G — Specifications and Blender benchmarks

Specifications Benchmarks Synonyms

Specifications

Technical data

CPU generation and family

Family
Ryzen
Form Factor
Desktops
Name
AMD Ryzen 7 8700G
Segment
Desktop
Series
Ryzen 8000 Series

CPU Cores and Base Frequency

Base Frequency
4.2 GHz
CPU Cores
8
CPU Threads
16
Max. Boost Clock
5.1 GHz
Overclocking
Yes
Turbo Frequency (1 Core)
5.1 GHz

Internal Graphics

GPU Frequency
2900 MHz
GPU name
AMD Radeon 780M
Graphics Cores
12

Memory & PCIe

Max. Memory
256 GB
Memory channels
2
Memory Speed (2x1R)
5200 MT/s
Memory Speed (2x2R)
5200 MT/s
Memory Speed (4x1R)
3600 MT/s
Memory Speed (4x2R)
3600 MT/s
Memory type
DDR5
PCIe
PCIe 4.0

Thermal Management

Configurable TDP
45-65 W
Configurable TDP (max)
65 W
Configurable TDP (min)
45 W
Default TDP
65 W
Maximum Operating Temperature
95 °C
TDP (PL1 / PBP, legacy combined label)
65 W

Technical details

Architecture
Zen 4
Codename
Phoenix
L2-Cache
8 MB
L3-Cache
16 MB
Release date
Q1/2024
Socket
AM5
Technology
TSMC 4nm FinFET

Positions in all rankings

Common positions AMD Ryzen 7 8700G CPU in popular benchmarks, for comparison with other models.

No data

Benchmarks

Performance tests CPU

Published results: 3

Blender Cycles

Each row uses one Blender version, operating system and compute backend.

Test and settings	AMD Ryzen 7 8700G
Blender 5.1.0 / CPU / Windows	258.286587 samples/min Submissions: 5
Blender 5.1.1 / CPU / Windows	279.093795 samples/min Submissions: 7
Blender 5.2.0 / CPU / Windows	265.265995 samples/min Submissions: 8

Individual system tests

Results were obtained on the reported systems. Test versions and settings remain separate; incomplete conditions do not support calculated model performance differences.

RandomX / XMRig 6.26.0 / 1M / 11 threads / linux

Result	Reported conditions
6597.742253 H/s	RandomX / XMRig 6.26.0 / 1M / 11 threads / linux System RAM: 64 GB OS: Linux x86_64 Motherboard: Micro-Star International Co., Ltd. / PRO B650-S WIFI (MS-7E26) Duration: 151.567 s User-submitted run; tuning and power settings are incomplete.
