Wybierz procesor 1
Wybierz procesor 2
MSI Radeon RX Vega 64 Iron 8G
Wybierz kartę graficzną 2
User rating
star star star star star
Wydany
Q3/2017
MSI Radeon RX Vega 64 Iron 8G

Karta graficzna MSI Radeon RX Vega 64 Iron 8G, specyfikacje i wzorce

1713 miejsce w rankingu ogólnym Karty graficzne (GPU)!
Szczegółowy przegląd karty wideo MSI Radeon RX Vega 64 Iron 8G, której data produkcji rozpoczęła się Q3/2017. Przedstawione są tutaj wszystkie specyfikacje techniczne, a także wyniki wydajności w postaci szacunków z nowoczesnych benchmarków. Początkowa częstotliwość zegara 1.247 GHz. Karta wideo obsługuje HBM2 i posiada na pokładzie pamięć wideo 8 GB. TDP wynosi 295 W. Zalecamy porównanie GPU z innymi modelami na naszej stronie internetowej w celu określenia najlepszej wydajności.

Specyfikacje

Dane techniczne
GPU
  • Na podstawie
    AMD RX Vega 64
  • Execution Units
    64
  • Układ GPU
    Vega 10 XT
  • Jednostki wyjściowe renderingu
    64
  • Shader
    4096
  • Jednostki tekstury
    256
Pamięć
  • Memory Bandwidth
    484 GB/s
  • Memory Bus
    2048 bit
  • Rozmiar pamięci
    8 GB
  • Memory Speed (legacy frequency label)
    945 MHz
  • Typ pamięci
    HBM2
Częstotliwość zegara
  • Częstotliwość podstawowa
    1247 MHz
  • Maksymalna częstotliwość
    1546 MHz
  • Game Clock
    —
  • Overclocking
    Tak
Zużycie energii
  • Maximum Junction Temperature
    —
  • TDP
    295 W
  • TDP (up)
    —
Chłodzenie
  • Cooler-Type
    Air cooling
  • Fan-Type
    Radial
  • Wentylator 1
    1 x 75 mm
  • Wentylator 2
    —
  • Noise (Idle)
    —
  • Noise (Load)
    —
Łączność
  • DisplayPort Ports
    3 × DisplayPort 1.4
  • Porty DVI
    —
  • HDCP Version
    —
  • Porty HDMI
    1 × HDMI 2.0b
  • Max. Wyświetlacze
    4
  • PCIe Interface
    PCIe 3.0 x16
  • Power Connectors
    2 x 8-Pin
  • USB-C Ports
    —
  • VGA Ports
    —
Zestaw funkcji
  • DirectX
    12_1
  • DLSS / FSR
    Nie
  • LED
    Non addressable LED
  • Maks. rozdzielczość
    7680 × 4320
  • Raytracing
    Nie
Obsługiwane kodeki wideo
  • AV1
    Nie
  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode
  • VP9
    Decode / Encode
Wymiary
  • Wysokość
    130 mm
  • Długość
    283 mm
  • Slot Size
    2 PCIe-Slots
  • Weight
    1040 g
  • Width
    40 mm
Dane dodatkowe
  • specyfikacja
    data sheet
  • Launch Price (historical)
    —
  • Part Number
    V803-869R
  • Process Technology
    14 nm
  • Data wydania
    Q3/2017
Pozycje we wszystkich rankingach

Wspólne stanowiska MSI Radeon RX Vega 64 Iron 8G GPU w popularnych benchmarkach, dla porównania z innymi modelami.

  • FP32 Performance (Single-precision TFLOPS)
    1059 place
  • 3DMark Benchmark
    1977 place
  • Battlefield 5
    1338 place
  • Shadow of the Tomb Raider
    1905 place
  • Crypto-Mining Ethereum Hashrate (MH/s)
    909 place
  • Crypto-Mining Ergo Hashrate (MH/s)
    167 place
  • Crypto-Mining Ravencoin Hashrate (MH/s)
    1067 place
  • Crypto-Mining Vertcoin Hashrate (MH/s)
    620 place

Benchmarki

Badania eksploatacyjne GPU

Porównaj wyniki popularnych benchmarków MSI Radeon RX Vega 64 Iron 8G z innymi kartami graficznymi, aby zrozumieć rzeczywistą szybkość działania GPU podczas przetwarzania treści.

Testy obejmują pracę ze zmiennoprzecinkową, tworzenie modeli 3D, wydobywanie kryptowalut.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archive: saved catalog source links. The original measurement method and test conditions have not been verified; current source pages may differ from the imported content. MSI Radeon RX Vega 64 Iron 8G

FP32 Performance (Single-precision TFLOPS)
Benchmark FP32 to 32-bitowe obliczenia zmiennoprzecinkowe dla GPU, które są wymagane w grach 3D.

Higher values are better in this metric.

12.66 TFLOPS
MSI Radeon RX Vega 64 Iron 8G
12.74 TFLOPS
12.74 TFLOPS
12.66 TFLOPS
3DMark Benchmark
3DMark jest przeznaczony dla graczy, overclockerów i twórców systemów, którzy chcą w pełni wykorzystać możliwości swojego sprzętu.

Higher values are better in this metric.

Battlefield 5
Battlefield 5 to realistyczna gra, z wbudowanym benchmarkiem, bardzo dobrze nadająca się jako test dla kart graficznych.

Higher values are better in this metric.

Shadow of the Tomb Raider
Shadow of the Tomb Raider posiada wbudowany benchmark, oparty na silniku Crystal Dynamics Foundation.

Higher values are better in this metric.

Crypto-Mining Ethereum Hashrate (MH/s)
Ethash to algorytm wydobywania kryptowaluty Ethereum, który w pełni wykorzystuje możliwości procesora graficznego.

Higher values are better in this metric.

Crypto-Mining Ergo Hashrate (MH/s)
Algorytm Autolykos, na którym oparta jest kryptowaluta Ergo, pozwala na wykorzystanie do wydobycia nie tylko nowoczesnych procesorów graficznych, ale także procesorów poprzedniej generacji.

Higher values are better in this metric.

Crypto-Mining Ravencoin Hashrate (MH/s)
Hashrate wydobycia kryptowaluty Ravencoin na algorytmie KawPoW jest najszybszy na nowoczesnych kartach graficznych.

Higher values are better in this metric.

24 MH/s
MSI Radeon RX Vega 64 Iron 8G
25 MH/s
25 MH/s
24 MH/s
Crypto-Mining Vertcoin Hashrate (MH/s)
Kryptowaluta VertCoin może być wydobywana zarówno na układach Nvidia, jak i AMD i jest interesująca, ponieważ doskonale radzi sobie na starych kartach graficznych, takich jak GTX1050, R9 290, a nawet GTX970.

Higher values are better in this metric.

0.75 MH/s
MSI Radeon RX Vega 64 Iron 8G
0.76 MH/s
0.76 MH/s
0.75 MH/s

Synonimy

Nearby models in the composite benchmark index.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted. Index 0–100: equal-weight mean of each score relative to the best saved score among models with both tests. Tests: Battlefield 5 + Shadow of the Tomb Raider. This index does not predict performance in every workload.

Recent models: test results with identified primary sources — Game frame rates

PowerColor Radeon RX Vega 64 PowerColor Radeon RX Vega 64 Zobacz
PowerColor Radeon RX Vega 64 Limited Edition PowerColor Radeon RX Vega 64 Limited Edition Zobacz
Sapphire Radeon RX Vega 64 Sapphire Radeon RX Vega 64 Zobacz
Sapphire Radeon RX Vega 64 LE Sapphire Radeon RX Vega 64 LE Zobacz
MSI Radeon RX Vega 64 Air Boost 8G MSI Radeon RX Vega 64 Air Boost 8G Zobacz
MSI Radeon RX Vega 64 8G MSI Radeon RX Vega 64 8G Zobacz
GIGABYTE Radeon RX Vega 64 Silver 8G GIGABYTE Radeon RX Vega 64 Silver 8G Zobacz
GIGABYTE Radeon RX Vega 64 8G GIGABYTE Radeon RX Vega 64 8G Zobacz

*

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.

Oceń kartę graficzną
MSI Radeon RX Vega 64 Iron 8G
