KFA2 GeForce RTX 3060 EX (1-Click OC) Dane techniczne układu GPU

Specyfikacje Benchmarki Synonimy

Specyfikacje

Dane techniczne

GPU

Na podstawie
NVIDIA GeForce RTX 3060
Execution Units
28
Układ GPU
GA106-300-A1
Jednostki wyjściowe renderingu
64
Shader
3584
Jednostki tekstury
112

Pamięć

Memory Bandwidth
360 GB/s
Memory Bus
192 bit
Rozmiar pamięci
12 GB
Memory Speed (legacy frequency label)
1875 MHz
Typ pamięci
GDDR6

Częstotliwość zegara

Częstotliwość podstawowa
1320 MHz
Maksymalna częstotliwość
1822 MHz + 2%
Game Clock
1807 MHz
Overclocking
Tak

Zużycie energii

Maximum Junction Temperature
—
TDP
170 W
TDP (up)
—

Chłodzenie

Cooler-Type
Air cooling
Fan-Type
Axial
Wentylator 1
2 x 102 mm
Wentylator 2
—
Noise (Idle)
0 dB / Silent
Noise (Load)
—

Łączność

DisplayPort Ports
3 × DisplayPort 1.4a
Porty DVI
—
HDCP Version
2.3
Porty HDMI
1 × HDMI 2.1
Max. Wyświetlacze
4
PCIe Interface
PCIe 4.0 x16
Power Connectors
1 x 8-Pin
USB-C Ports
—
VGA Ports
—

Zestaw funkcji

DirectX
12_2
DLSS / FSR
Tak
LED
Addressable LED
Maks. rozdzielczość
7680 × 4320
Raytracing
Tak

Obsługiwane kodeki wideo

AV1
Decode
h264
Decode / Encode
h265 / HEVC
Decode / Encode
VP8
Decode
VP9
Decode

Wymiary

Wysokość
139 mm
Długość
299 mm
Slot Size
3 PCIe-Slots
Weight
—
Width
50 mm

Dane dodatkowe

specyfikacja
data sheet
Launch Price (historical)
—
Part Number
36NOL7MD2NEK
Process Technology
8 nm
Data wydania
Q1/2021

Pozycje we wszystkich rankingach

Wspólne stanowiska KFA2 GeForce RTX 3060 EX (1-Click OC) GPU w popularnych benchmarkach, dla porównania z innymi modelami.

FP32 Performance (Single-precision TFLOPS)

993 place
3DMark Benchmark

1519 place
Battlefield 5

1427 place
Shadow of the Tomb Raider

1160 place
Crypto-Mining Ethereum Hashrate (MH/s)

1773 place
Crypto-Mining Ergo Hashrate (MH/s)

909 place
Crypto-Mining Ravencoin Hashrate (MH/s)

1360 place
Crypto-Mining Vertcoin Hashrate (MH/s)

1713 place

Manufacturer versions

Board specifications and benchmark results are specific to each version.

Palit GeForce RTX 3060 Dual 12GB

Palit · 12 GB

Palit GeForce RTX 3060 Dual OC 12GB

Palit · 12 GB

Palit GeForce RTX 3060 Infinity 2 OC 12GB

Palit · 12 GB

Palit GeForce RTX 3060 StormX 12GB

Palit · 12 GB

Palit GeForce RTX 3060 StormX OC 12GB

Palit · 12 GB

All models based on this GPU

Benchmarki

Badania eksploatacyjne GPU

Published results: 23

Game frame rates

Each row uses one game, resolution, test suite and graphics mode.

Test and settings	KFA2 GeForce RTX 3060 EX (1-Click OC)
Budget GPU suite 2026 / Alan Wake 2 / 1920x1080 / Mittel-Preset / DLSS/FSR Quality / RT off	49.7 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Anno 117 / 1920x1080 / Ultra-Hoch-Preset / DLSS/FSR Quality / RT off	42.7 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / ARC Raiders / 1920x1080 / Episch-Preset / DLSS/FSR Quality / RT off	87.3 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Assassin's Creed Shadows / 1920x1080 / Hoch-Preset / DLSS/FSR Quality / RT off	43 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Battlefield 6 / 1920x1080 / Hemmungslos-Preset / DLSS/FSR Quality	54.8 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Borderlands 4 / 1920x1080 / Sehr-Hoch-Preset / DLSS/FSR Quality	54.8 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Call of Duty: Black Ops 7 / 1920x1080 / Extrem-Preset / DLSS/FSR Quality / RT off	77.4 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Crimson Desert / 1920x1080 / Filmisch-Preset / DLSS/FSR Quality / RT on	50.1 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Cyberpunk 2077 / 1920x1080 / Ultra-Preset / DLSS/FSR Quality / RT off	67.2 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Death Stranding 2 / 1920x1080 / Sehr-Hoch-Preset / DLSS/FSR Quality / RT off	44.6 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Doom: The Dark Ages / 1920x1080 / Ultra-Albtraum-Preset / DLSS/FSR Quality / RT on	53.5 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / F1 25 / 1920x1080 / Ultrahoch-Preset, VRS Aus / DLSS/FSR Quality / RT off	82.3 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled

More tests: 11

Test and settings	KFA2 GeForce RTX 3060 EX (1-Click OC)
Budget GPU suite 2026 / Hogwarts Legacy / 1920x1080 / Ultra-Preset / DLSS/FSR Quality / RT off	55.3 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Indiana Jones und der große Kreis / 1920x1080 / Hyper-Preset, Texturen Mittel für 8 GB! / DLSS/FSR Quality / RT on	59.4 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Kingdom Come: Deliverance 2 / 1920x1080 / Ultra-Preset-Preset / DLSS/FSR Quality	46 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Mafia: The Old Country / 1920x1080 / Hoch-Preset / DLSS/FSR Quality	51.6 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Pragmata / 1920x1080 / Quality-Preset, sämtliche Grafikdetails maximiert / DLSS/FSR Quality / RT off	66.7 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Resident Evil Requiem / 1920x1080 / Maximal-Preset, Haarsträhnen Ein / DLSS/FSR Quality / RT off	76.4 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Star Wars Outlaws / 1920x1080 / Ultra-Preset, RTXDL Aus / DLSS/FSR Quality / RT on	45.4 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / The Elder Scrolls IV: Oblivion / 1920x1080 / Hoch-Preset-Preset / DLSS/FSR Quality / RT off	53.2 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / The Last of Us Part II / 1920x1080 / Sehr-Hoch-Preset, 16×AF / DLSS/FSR Quality	47.2 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / The Outer Worlds 2 / 1920x1080 / Hoch-Preset / DLSS/FSR Quality / RT off	52.3 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled
Budget GPU suite 2026 / Warhammer 40k: Space Marine 2 / 1920x1080 / Ultra-Preset / DLSS/FSR Quality	61.3 FPS Base GPU test: GeForce RTX 3060 (12 GB) VRAM: 12 GBTest CPU: AMD Ryzen 7 9800X3DSystem RAM: 48 GB DDR5-6000 30-38-38-96OS: Windows 11 25H2Rendering: DLSS/FSR QualityDriver: 596.21HVCI: enabledVBS: enabled

A base GPU test is a reference for cards using that GPU and the same memory capacity. Board overclocking, cooling and power limits can change the result.

Porównaj wyniki popularnych benchmarków KFA2 GeForce RTX 3060 EX (1-Click OC) z innymi kartami graficznymi, aby zrozumieć rzeczywistą szybkość działania GPU podczas przetwarzania treści.

Testy obejmują pracę ze zmiennoprzecinkową, tworzenie modeli 3D, wydobywanie kryptowalut.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archived results. The original measurement method and test conditions have not been verified.

FP32 Performance (Single-precision TFLOPS)

Benchmark FP32 to 32-bitowe obliczenia zmiennoprzecinkowe dla GPU, które są wymagane w grach 3D.

Higher values are better in this metric.

13.06 TFLOPS

KFA2 GeForce RTX 3060 EX (1-Click OC)

13.07 TFLOPS

AMD Radeon Pro VII

13.07 TFLOPS

NVIDIA GeForce RTX 3060 Laptop (Mobile) - 115 W

13.06 TFLOPS

Colorful iGame GeForce RTX 3060 Ultra W OC 12G-V

Wszystkie wyniki benchmarków

3DMark Benchmark

3DMark jest przeznaczony dla graczy, overclockerów i twórców systemów, którzy chcą w pełni wykorzystać możliwości swojego sprzętu.

Higher values are better in this metric.

8924

KFA2 GeForce RTX 3060 EX (1-Click OC)

8935

ASUS Dual GeForce RTX 2060 SUPER EVO OC Edition

8935

ASUS Dual GeForce RTX 2060 SUPER EVO V2 OC Edition

8924

Colorful iGame GeForce RTX 3060 bilibili E-sports Edition OC 12G-V

Wszystkie wyniki benchmarków

Battlefield 5

Battlefield 5 to realistyczna gra, z wbudowanym benchmarkiem, bardzo dobrze nadająca się jako test dla kart graficznych.

Higher values are better in this metric.

54 fps

KFA2 GeForce RTX 3060 EX (1-Click OC)

55 fps

MSI GeForce RTX 3060 GAMING X Trio 12G

55 fps

MSI GeForce RTX 3060 GAMING X 12G

54 fps

ZOTAC GAMING GeForce RTX 3060 Twin Edge OC

Wszystkie wyniki benchmarków

Shadow of the Tomb Raider

Shadow of the Tomb Raider posiada wbudowany benchmark, oparty na silniku Crystal Dynamics Foundation.

Higher values are better in this metric.

43 fps

KFA2 GeForce RTX 3060 EX (1-Click OC)

44 fps

MSI GeForce RTX 3060 GAMING X Trio 12G

44 fps

MSI GeForce RTX 3060 GAMING X 12G

43 fps

ZOTAC GAMING GeForce RTX 3060 Twin Edge OC

Wszystkie wyniki benchmarków

Crypto-Mining Ethereum Hashrate (MH/s)

Ethash to algorytm wydobywania kryptowaluty Ethereum, który w pełni wykorzystuje możliwości procesora graficznego.

Higher values are better in this metric.

36 MH/s

KFA2 GeForce RTX 3060 EX (1-Click OC)

38 MH/s

ASUS ROG Strix GeForce GTX 1080

38 MH/s

ASUS Turbo GeForce GTX 1080

36 MH/s

INNO3D GeForce RTX 3060 Twin X2 LHR

Wszystkie wyniki benchmarków

Crypto-Mining Ergo Hashrate (MH/s)

Algorytm Autolykos, na którym oparta jest kryptowaluta Ergo, pozwala na wykorzystanie do wydobycia nie tylko nowoczesnych procesorów graficznych, ale także procesorów poprzedniej generacji.

Higher values are better in this metric.

109 MH/s

KFA2 GeForce RTX 3060 EX (1-Click OC)

110 MH/s

GIGABYTE Radeon RX 6800 Gaming 16G

110 MH/s

EVGA GeForce RTX 3060 XC Gaming

109 MH/s

MSI GeForce RTX 3060 GAMING X Trio 12G

Wszystkie wyniki benchmarków

Crypto-Mining Ravencoin Hashrate (MH/s)

Hashrate wydobycia kryptowaluty Ravencoin na algorytmie KawPoW jest najszybszy na nowoczesnych kartach graficznych.

Higher values are better in this metric.

21 MH/s

KFA2 GeForce RTX 3060 EX (1-Click OC)

22 MH/s

MSI GeForce RTX 3060 Ti Gaming Trio 8G

22 MH/s

NVIDIA GeForce RTX 3060 Ti Founders Edition

21 MH/s

ZOTAC GAMING GeForce RTX 3060 Twin Edge OC

Wszystkie wyniki benchmarków

Crypto-Mining Vertcoin Hashrate (MH/s)

Kryptowaluta VertCoin może być wydobywana zarówno na układach Nvidia, jak i AMD i jest interesująca, ponieważ doskonale radzi sobie na starych kartach graficznych, takich jak GTX1050, R9 290, a nawet GTX970.

Higher values are better in this metric.

0.4 MH/s

KFA2 GeForce RTX 3060 EX (1-Click OC)

0.41 MH/s

ASUS ROG Strix GeForce RTX 3060 OC Edition

0.41 MH/s

ZOTAC GAMING GeForce RTX 3060 AMP White Edition

0.4 MH/s

MSI Radeon RX 570 Armor 4G

Wszystkie wyniki benchmarków

Synonimy

Nearby models in the composite benchmark index.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted. Index 0–100: equal-weight mean of each score relative to the best saved score among models with both tests. Tests: Battlefield 5 + Shadow of the Tomb Raider. This index does not predict performance in every workload.

Recent models: test results with identified primary sources — Game frame rates

ASUS Dual GeForce RTX 3060 Zobacz

ASUS KO GeForce RTX 3060 Zobacz

ASUS Phoenix GeForce RTX 3060 Zobacz

ASUS ROG Strix GeForce RTX 3060 Zobacz

GALAX GeForce RTX 3060 EX W (1-Click OC) Zobacz

GALAX GeForce RTX 3060 EX (1-Click OC) Zobacz

Colorful iGame GeForce RTX 3060 Ultra W OC 12G-V Zobacz

Colorful iGame GeForce RTX 3060 bilibili E-sports Edition OC 12G-V Zobacz

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.
