PowerColor Radeon RX 6700 XT

Scheda grafica PowerColor Radeon RX 6700 XT, specifiche e parametri di riferimento

724 posto nella classifica generale Schede grafiche (GPU)!
Una panoramica dettagliata della scheda video PowerColor Radeon RX 6700 XT, la cui data di produzione è iniziata in Q1/2021. Tutte le specifiche tecniche sono presentate qui, così come i risultati delle prestazioni sotto forma di stime da benchmark moderni. Frequenza di clock iniziale 2.321 GHz. La scheda video supporta GDDR6 e contiene 12 GB memoria video a bordo. Il TDP è 230 W. Si consiglia di confrontare la GPU con altri modelli presenti sul nostro sito web per determinare le prestazioni migliori.

Specifiche

Dati tecnici
GPU
  • Basato su
    AMD Radeon RX 6700 XT
  • Execution Units
    40
  • Chip GPU
    Navi 22 XT
  • Unità di uscita del rendering
    64
  • Shader
    2560
  • Unità di texture
    160
Memoria
  • Memory Bandwidth
    384 GB/s
  • Memory Bus
    192 bit
  • Dimensione della memoria
    12 GB
  • Memory Speed (legacy frequency label)
    2000 MHz
  • Tipo di memoria
    GDDR6
Frequenza di clock
  • Frequenza di base
    2321 MHz
  • Frequenza massima
    2581 MHz
  • Game Clock
    2424 MHz
  • Overclock
    Sì
Consumo di energia
  • Maximum Junction Temperature
    —
  • TDP
    230 W
  • TDP (up)
    —
Raffreddamento
  • Cooler-Type
    Air cooling
  • Fan-Type
    Axial
  • Ventilatore 1
    2 x 90 mm
  • Ventilatore 2
    —
  • Noise (Idle)
    0 dB / Silent
  • Noise (Load)
    —
Connettività
  • DisplayPort Ports
    3 × DisplayPort 1.4a
  • Porte DVI
    —
  • HDCP Version
    2.3
  • Porte HDMI
    1 × HDMI 2.1
  • Max. Visualizzazioni
    4
  • PCIe Interface
    PCIe 4.0 x16
  • Power Connectors
    1 x 6-Pin, 1 x 8-Pin
  • USB-C Ports
    —
  • VGA Ports
    —
Featureset
  • DirectX
    12_2
  • DLSS / FSR
    No
  • LED
    Non addressable LED
  • Risoluzione massima
    7680 × 4320
  • Raytracing
    Sì
Codec video supportati
  • AV1
    Decode
  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode / Encode
  • VP9
    Decode / Encode
Dimensioni
  • Altezza
    110 mm
  • Lunghezza
    267 mm
  • Slot Size
    2 PCIe-Slots
  • Weight
    —
  • Width
    40 mm
Dati aggiuntivi
  • Specifica
    data sheet
  • Launch Price (historical)
    —
  • Part Number
    AXRX 6700XT 12GBD6-M3DH
  • Process Technology
    7 nm
  • Data di rilascio
    Q1/2021
Posizioni in tutte le classifiche

Posizioni comuni PowerColor Radeon RX 6700 XT GPU in benchmark popolari, per un confronto con altri modelli.

  • FP32 Performance (Single-precision TFLOPS)
    965 place
  • 3DMark Benchmark
    840 place
  • Battlefield 5
    728 place
  • Shadow of the Tomb Raider
    697 place
  • Crypto-Mining Ethereum Hashrate (MH/s)
    964 place
  • Crypto-Mining Ergo Hashrate (MH/s)
    1172 place
  • Crypto-Mining Ravencoin Hashrate (MH/s)
    961 place

Benchmark (test)

Test di performance GPU

Confrontare i punteggi dei benchmark più diffusi PowerColor Radeon RX 6700 XT con altre schede grafiche per capire la reale velocità della GPU nell'elaborazione dei contenuti.

I test includono il lavoro con la virgola mobile, la creazione di modelli 3D, il mining di criptovalute.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archive: saved catalog source links. The original measurement method and test conditions have not been verified; current source pages may differ from the imported content. PowerColor Radeon RX 6700 XT

FP32 Performance (Single-precision TFLOPS)
Benchmark FP32 è un calcolo in virgola mobile a 32 bit per la GPU che è richiesto per il gioco 3D.

Higher values are better in this metric.

13.21 TFLOPS
PowerColor Radeon RX 6700 XT
13.38 TFLOPS
13.28 TFLOPS
13.21 TFLOPS
3DMark Benchmark
3DMark è progettato per i giocatori, gli overclocker e i costruttori di sistemi che vogliono ottenere il massimo dal loro hardware.

Higher values are better in this metric.

Battlefield 5
Battlefield 5 è un gioco realistico, con un benchmark incorporato, molto adatto come test per le schede grafiche.

Higher values are better in this metric.

Shadow of the Tomb Raider
Shadow of the Tomb Raider ha un benchmark incorporato, basato sul motore Crystal Dynamics Foundation.

Higher values are better in this metric.

Crypto-Mining Ethereum Hashrate (MH/s)
Ethash è un algoritmo per il mining della criptovaluta Ethereum che sfrutta al massimo la GPU.

Higher values are better in this metric.

46 MH/s
PowerColor Radeon RX 6700 XT
47 MH/s
47 MH/s
46 MH/s
Crypto-Mining Ergo Hashrate (MH/s)
L'algoritmo Autolykos, su cui si basa la criptovaluta Ergo, permette non solo alle moderne GPU di essere utilizzate per il mining, ma anche alla passata generazione di GPU.

Higher values are better in this metric.

Crypto-Mining Ravencoin Hashrate (MH/s)
Hashrate mining della criptovaluta Ravencoin sull'algoritmo KawPoW è il più veloce sulle moderne schede video.

Higher values are better in this metric.

Sinonimi

Nearby models in the composite benchmark index.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted. Index 0–100: equal-weight mean of each score relative to the best saved score among models with both tests. Tests: Battlefield 5 + Shadow of the Tomb Raider. This index does not predict performance in every workload.

Recent models: test results with identified primary sources — Game frame rates

SAPPHIRE PULSE Radeon RX 6700 XT SAPPHIRE PULSE Radeon RX 6700 XT Vedi
SAPPHIRE Radeon RX 6700 XT SAPPHIRE Radeon RX 6700 XT Vedi
XFX Speedster QICK 319 Radeon RX 6700 XT Core Gaming XFX Speedster QICK 319 Radeon RX 6700 XT Core Gaming Vedi
XFX Speedster SWFT 309 Radeon RX 6700 XT Core Gaming XFX Speedster SWFT 309 Radeon RX 6700 XT Core Gaming Vedi
PowerColor Hellhound Spectral White Radeon RX 6700 XT PowerColor Hellhound Spectral White Radeon RX 6700 XT Vedi
PowerColor Hellhound Radeon RX 6700 XT PowerColor Hellhound Radeon RX 6700 XT Vedi
PowerColor Fighter Radeon RX 6700 XT PowerColor Fighter Radeon RX 6700 XT Vedi
MSI Radeon RX 6700 XT MECH 2X 12G MSI Radeon RX 6700 XT MECH 2X 12G Vedi

*

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.
