GALAX GeForce RTX 3070 Ti SG (1-Click OC)
Seleziona la scheda video 2
User rating
star star star star star
Rilasciato
Q2/2021
GALAX GeForce RTX 3070 Ti SG (1-Click OC)

Scheda grafica GALAX GeForce RTX 3070 Ti SG (1-Click OC), specifiche e parametri di riferimento

422 posto nella classifica generale Schede grafiche (GPU)!
Una panoramica dettagliata della scheda video GALAX GeForce RTX 3070 Ti SG (1-Click OC), la cui data di produzione è iniziata in Q2/2021. Tutte le specifiche tecniche sono presentate qui, così come i risultati delle prestazioni sotto forma di stime da benchmark moderni. Frequenza di clock iniziale 1.580 GHz. La scheda video supporta GDDR6X e contiene 8 GB memoria video a bordo. Il TDP è 290 W. Si consiglia di confrontare la GPU con altri modelli presenti sul nostro sito web per determinare le prestazioni migliori.

Specifiche

Dati tecnici
GPU
  • Basato su
    NVIDIA GeForce RTX 3070 Ti
  • Execution Units
    48
  • Chip GPU
    GA104-400-A1
  • Unità di uscita del rendering
    96
  • Shader
    6144
  • Unità di texture
    192
Memoria
  • Memory Bandwidth
    608 GB/s
  • Memory Bus
    256 bit
  • Dimensione della memoria
    8 GB
  • Memory Speed (legacy frequency label)
    1188 MHz
  • Tipo di memoria
    GDDR6X
Frequenza di clock
  • Frequenza di base
    1580 MHz
  • Frequenza massima
    1815 MHz + 3%
  • Game Clock
    —
  • Overclock
    Sì
Consumo di energia
  • Maximum Junction Temperature
    93 °C
  • TDP
    290 W
  • TDP (up)
    —
Raffreddamento
  • Cooler-Type
    Air cooling
  • Fan-Type
    Axial
  • Ventilatore 1
    3 x 92 mm
  • Ventilatore 2
    —
  • Noise (Idle)
    0 dB / Silent
  • Noise (Load)
    —
Connettività
  • DisplayPort Ports
    3 × DisplayPort 1.4a
  • Porte DVI
    —
  • HDCP Version
    2.3
  • Porte HDMI
    1 × HDMI 2.1
  • Max. Visualizzazioni
    4
  • PCIe Interface
    PCIe 4.0 x16
  • Power Connectors
    2 x 8-Pin
  • USB-C Ports
    —
  • VGA Ports
    —
Featureset
  • DirectX
    12_2
  • DLSS / FSR
    Sì
  • LED
    Addressable LED
  • Risoluzione massima
    7680 × 4320
  • Raytracing
    Sì
Codec video supportati
  • AV1
    Decode
  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode
  • VP9
    Decode
Dimensioni
  • Altezza
    130 mm
  • Lunghezza
    329 mm
  • Slot Size
    3 PCIe-Slots
  • Weight
    —
  • Width
    61 mm
Dati aggiuntivi
  • Specifica
    data sheet
  • Launch Price (historical)
    —
  • Part Number
    37ISM6MD4BSG
  • Process Technology
    8 nm
  • Data di rilascio
    Q2/2021
Posizioni in tutte le classifiche

Posizioni comuni GALAX GeForce RTX 3070 Ti SG (1-Click OC) GPU in benchmark popolari, per un confronto con altri modelli.

  • FP32 Performance (Single-precision TFLOPS)
    419 place
  • 3DMark Benchmark
    461 place
  • Battlefield 5
    447 place
  • Shadow of the Tomb Raider
    412 place
  • Crypto-Mining Ethereum Hashrate (MH/s)
    628 place
  • Crypto-Mining Ergo Hashrate (MH/s)
    281 place
  • Crypto-Mining Ravencoin Hashrate (MH/s)
    298 place

Manufacturer versions

Board specifications and benchmark results are specific to each version.

All models based on this GPU

Benchmark (test)

Test di performance GPU

Confrontare i punteggi dei benchmark più diffusi GALAX GeForce RTX 3070 Ti SG (1-Click OC) con altre schede grafiche per capire la reale velocità della GPU nell'elaborazione dei contenuti.

I test includono il lavoro con la virgola mobile, la creazione di modelli 3D, il mining di criptovalute.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archive: saved catalog source links. The original measurement method and test conditions have not been verified; current source pages may differ from the imported content. GALAX GeForce RTX 3070 Ti SG (1-Click OC)

FP32 Performance (Single-precision TFLOPS)
Benchmark FP32 è un calcolo in virgola mobile a 32 bit per la GPU che è richiesto per il gioco 3D.

Higher values are better in this metric.

22.3 TFLOPS
GALAX GeForce RTX 3070 Ti SG (1-Click OC)
22.49 TFLOPS
22.49 TFLOPS
22.3 TFLOPS
3DMark Benchmark
3DMark è progettato per i giocatori, gli overclocker e i costruttori di sistemi che vogliono ottenere il massimo dal loro hardware.

Higher values are better in this metric.

Battlefield 5
Battlefield 5 è un gioco realistico, con un benchmark incorporato, molto adatto come test per le schede grafiche.

Higher values are better in this metric.

Shadow of the Tomb Raider
Shadow of the Tomb Raider ha un benchmark incorporato, basato sul motore Crystal Dynamics Foundation.

Higher values are better in this metric.

69 fps
GALAX GeForce RTX 3070 Ti SG (1-Click OC)
70 fps
70 fps
69 fps
Crypto-Mining Ethereum Hashrate (MH/s)
Ethash è un algoritmo per il mining della criptovaluta Ethereum che sfrutta al massimo la GPU.

Higher values are better in this metric.

Crypto-Mining Ergo Hashrate (MH/s)
L'algoritmo Autolykos, su cui si basa la criptovaluta Ergo, permette non solo alle moderne GPU di essere utilizzate per il mining, ma anche alla passata generazione di GPU.

Higher values are better in this metric.

170 MH/s
GALAX GeForce RTX 3070 Ti SG (1-Click OC)
182 MH/s
182 MH/s
170 MH/s
Crypto-Mining Ravencoin Hashrate (MH/s)
Hashrate mining della criptovaluta Ravencoin sull'algoritmo KawPoW è il più veloce sulle moderne schede video.

Higher values are better in this metric.

Sinonimi

Nearby models in the composite benchmark index.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted. Index 0–100: equal-weight mean of each score relative to the best saved score among models with both tests. Tests: Battlefield 5 + Shadow of the Tomb Raider. This index does not predict performance in every workload.

Recent models: test results with identified primary sources — Game frame rates

KFA2 GeForce RTX 3070 Ti EX (1-Click OC) KFA2 GeForce RTX 3070 Ti EX (1-Click OC) Vedi
KFA2 GeForce RTX 3070 Ti SG (1-Click OC) KFA2 GeForce RTX 3070 Ti SG (1-Click OC) Vedi
ASUS ROG Strix GeForce RTX 3070 Ti ASUS ROG Strix GeForce RTX 3070 Ti Vedi
ASUS TUF Gaming GeForce RTX 3070 Ti ASUS TUF Gaming GeForce RTX 3070 Ti Vedi
GALAX GeForce RTX 3070 Ti EX White (1-Click OC) GALAX GeForce RTX 3070 Ti EX White (1-Click OC) Vedi
GALAX GeForce RTX 3070 Ti EX (1-Click OC) GALAX GeForce RTX 3070 Ti EX (1-Click OC) Vedi
EVGA GeForce RTX 3070 Ti XC3 ULTRA GAMING EVGA GeForce RTX 3070 Ti XC3 ULTRA GAMING Vedi
ASUS TUF Gaming GeForce RTX 3070 Ti OC Edition ASUS TUF Gaming GeForce RTX 3070 Ti OC Edition Vedi

*

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.
