Seleziona il processore 1
Seleziona il processore 2
ASUS Radeon RX 6800
Seleziona la scheda video 2
User rating
star star star star star
Rilasciato
Q4/2020
ASUS Radeon RX 6800

Scheda grafica ASUS Radeon RX 6800, specifiche e parametri di riferimento

455 posto nella classifica generale Schede grafiche (GPU)!
Una panoramica dettagliata della scheda video ASUS Radeon RX 6800, la cui data di produzione è iniziata in Q4/2020. Tutte le specifiche tecniche sono presentate qui, così come i risultati delle prestazioni sotto forma di stime da benchmark moderni. Frequenza di clock iniziale 1.700 GHz. La scheda video supporta GDDR6 e contiene 16 GB memoria video a bordo. Il TDP è 250 W. Si consiglia di confrontare la GPU con altri modelli presenti sul nostro sito web per determinare le prestazioni migliori.

Specifiche

Dati tecnici
GPU
  • Basato su
    AMD Radeon RX 6800
  • Execution Units
    60
  • Chip GPU
    Navi 21
  • Unità di uscita del rendering
    96
  • Shader
    3840
  • Unità di texture
    240
Memoria
  • Memory Bandwidth
    512 GB/s
  • Memory Bus
    256 bit
  • Dimensione della memoria
    16 GB
  • Memory Speed (legacy frequency label)
    2000 MHz
  • Tipo di memoria
    GDDR6
Frequenza di clock
  • Frequenza di base
    1700 MHz
  • Frequenza massima
    2105 MHz
  • Game Clock
    1815 MHz
  • Overclock
    Sì
Consumo di energia
  • Maximum Junction Temperature
    —
  • TDP
    250 W
  • TDP (up)
    285 W
Raffreddamento
  • Cooler-Type
    Air cooling
  • Fan-Type
    Axial
  • Ventilatore 1
    3 x 85 mm
  • Ventilatore 2
    —
  • Noise (Idle)
    0 dB / Silent
  • Noise (Load)
    35 dB
Connettività
  • DisplayPort Ports
    2 × DisplayPort 1.4a
  • Porte DVI
    —
  • HDCP Version
    2.3
  • Porte HDMI
    1 × HDMI 2.1
  • Max. Visualizzazioni
    4
  • PCIe Interface
    PCIe 4.0 x16
  • Power Connectors
    2 x 8-Pin
  • USB-C Ports
    1 × USB-C
  • VGA Ports
    —
Featureset
  • DirectX
    12_2
  • DLSS / FSR
    No
  • LED
    Non addressable LED
  • Risoluzione massima
    7680 × 4320
  • Raytracing
    Sì
Codec video supportati
  • AV1
    Decode
  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode / Encode
  • VP9
    Decode / Encode
Dimensioni
  • Altezza
    120 mm
  • Lunghezza
    267 mm
  • Slot Size
    2 PCIe-Slots
  • Weight
    —
  • Width
    40 mm
Dati aggiuntivi
  • Specifica
    data sheet
  • Launch Price (historical)
    —
  • Part Number
    RX6800-16G
  • Process Technology
    7 nm
  • Data di rilascio
    Q4/2020
Posizioni in tutte le classifiche

Posizioni comuni ASUS Radeon RX 6800 GPU in benchmark popolari, per un confronto con altri modelli.

  • FP32 Performance (Single-precision TFLOPS)
    793 place
  • 3DMark Benchmark
    435 place
  • Battlefield 5
    403 place
  • Shadow of the Tomb Raider
    475 place
  • Crypto-Mining Ethereum Hashrate (MH/s)
    628 place
  • Crypto-Mining Ergo Hashrate (MH/s)
    867 place
  • Crypto-Mining Ravencoin Hashrate (MH/s)
    677 place
  • Crypto-Mining Vertcoin Hashrate (MH/s)
    433 place

Manufacturer versions

Board specifications and benchmark results are specific to each version.

All models based on this GPU

Benchmark (test)

Test di performance GPU

Confrontare i punteggi dei benchmark più diffusi ASUS Radeon RX 6800 con altre schede grafiche per capire la reale velocità della GPU nell'elaborazione dei contenuti.

I test includono il lavoro con la virgola mobile, la creazione di modelli 3D, il mining di criptovalute.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archive: saved catalog source links. The original measurement method and test conditions have not been verified; current source pages may differ from the imported content. ASUS Radeon RX 6800

FP32 Performance (Single-precision TFLOPS)
Benchmark FP32 è un calcolo in virgola mobile a 32 bit per la GPU che è richiesto per il gioco 3D.

Higher values are better in this metric.

16.17 TFLOPS
ASUS Radeon RX 6800
16.2 TFLOPS
16.2 TFLOPS
16.17 TFLOPS
3DMark Benchmark
3DMark è progettato per i giocatori, gli overclocker e i costruttori di sistemi che vogliono ottenere il massimo dal loro hardware.

Higher values are better in this metric.

Battlefield 5
Battlefield 5 è un gioco realistico, con un benchmark incorporato, molto adatto come test per le schede grafiche.

Higher values are better in this metric.

Shadow of the Tomb Raider
Shadow of the Tomb Raider ha un benchmark incorporato, basato sul motore Crystal Dynamics Foundation.

Higher values are better in this metric.

Crypto-Mining Ethereum Hashrate (MH/s)
Ethash è un algoritmo per il mining della criptovaluta Ethereum che sfrutta al massimo la GPU.

Higher values are better in this metric.

Crypto-Mining Ergo Hashrate (MH/s)
L'algoritmo Autolykos, su cui si basa la criptovaluta Ergo, permette non solo alle moderne GPU di essere utilizzate per il mining, ma anche alla passata generazione di GPU.

Higher values are better in this metric.

Crypto-Mining Ravencoin Hashrate (MH/s)
Hashrate mining della criptovaluta Ravencoin sull'algoritmo KawPoW è il più veloce sulle moderne schede video.

Higher values are better in this metric.

Crypto-Mining Vertcoin Hashrate (MH/s)
La criptovaluta VertCoin può essere estratta sia su Nvidia che su AMD ed è interessante perché si estrae perfettamente su vecchie GPU come GTX1050, R9 290 e persino GTX970.

Higher values are better in this metric.

Sinonimi

Nearby models in the composite benchmark index.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted. Index 0–100: equal-weight mean of each score relative to the best saved score among models with both tests. Tests: Battlefield 5 + Shadow of the Tomb Raider. This index does not predict performance in every workload.

Recent models: test results with identified primary sources — Game frame rates

GIGABYTE Radeon RX 6800 GIGABYTE Radeon RX 6800 Vedi
GIGABYTE Radeon RX 6800 Gaming 16G GIGABYTE Radeon RX 6800 Gaming 16G Vedi
MSI Radeon RX 6800 MSI Radeon RX 6800 Vedi
MSI Radeon RX 6800 Gaming Trio 16G MSI Radeon RX 6800 Gaming Trio 16G Vedi
AMD Radeon RX 6800 AMD Radeon RX 6800 Vedi
ASRock Radeon RX 6800 Challenger Pro 16G OC ASRock Radeon RX 6800 Challenger Pro 16G OC Vedi
ZOTAC GAMING GeForce RTX 3070 Ti Trinity ZOTAC GAMING GeForce RTX 3070 Ti Trinity Vedi
PNY GeForce RTX 3070 Ti 8GB XLR8 Gaming UPRISING EPIC-X RGB Triple Fan PNY GeForce RTX 3070 Ti 8GB XLR8 Gaming UPRISING EPIC-X RGB Triple Fan Vedi

*

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.
