Graphics card ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme, specifications and benchmarks

Key features of the graphics card ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme.

• Based on
  NVIDIA GeForce RTX 2080 Ti
• GPU Chip
  TU102
• Execution units
  68
• Shader
  4352
• Render Output Units
  88
• Texture Units
  272

The characteristics of the video memory on board the graphics card. The higher the better.

• Memory Size
  11 GB
• Memory Type
  GDDR6
• Memory Speed
  1.8 GHz
• Memory Bandwith
  634 GB/s
• Memory Interface
  352 bit

Video card clock speed and overclocking potential ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme.

• Base Clock
  1.350 GHz
• Boost Clock
  1.815 GHz+ 17 %
• Avg (Game) Clock
  1.545 GHz
• Overclocking
  Yes

Connectors, the number of thermal watts emitted in normal mode and at overclocking.

• TDP
  300 W+ 20 %
• TDP (up)
  --
• Tjunction max
  --
• PCIe-Power
  2 x 8-Pin

Cooling system parameters, connectors and fan types ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Fan 1
  3 x 90 mm
• Noise (Idle)
  0 dB / Silent
• Fan 2
  --
• Noise (Load)
  --

Connectivity and connections.

• Max. Displays
  4
• HDCP-Version
  2.2
• HDMI Ports
  1x HDMI v2.0b
• DP Ports
  3x DP v1.4a
• DVI Ports
  --
• VGA Ports
  --
• USB-C Ports
  1

Hardware capabilities and maintaining the API.

• Max. resolution
  7680x4320
• DirectX
  12_2
• Raytracing
  Yes
• DLSS / FSR
  Yes
• LED
  ZOTAC SPECTRA

Built-in support for video and image compression standards.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  No

• Length
  324 mm
• Height
  136 mm
• Width
  59 mm
• Width (Slots)
  3 PCIe-Slots
• Weight
  --

• GPU Interface
  PCIe 3.0 x 16
• Release date
  Q3/2018
• Release price
  --
• Structure size
  12 nm
• Part-no
  ZT-T20810B-10P
• Documents
  data sheet

Common positions ZOTAC GAMING GeForce RTX 2080 Ti AMP Extreme GPU in popular benchmarks, for comparison with other models.

• FP32 Performance (Single-precision TFLOPS)
  758 place
• Battlefield 5
  419 place
• Shadow of the Tomb Raider
  487 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  520 place
• Crypto-Mining Ergo Hashrate (MH/s)
  746 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  365 place
• 3DMark Benchmark
  390 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  345 place
