MSI Radeon RX 6650 XT GAMING X 8G

Graphics card MSI Radeon RX 6650 XT GAMING X 8G, specifications and benchmarks

1131 place in the overall ranking Graphics Cards!
It is a detailed review of MSI Radeon RX 6650 XT GAMING X 8G, the date of manufacture started in Q2/2022. Here are all specifications and the results of performance in the form of modern benchmark estimations. The base clock frequency is 2.055 GHz. The GPU supports GDDR6 with an 8 GB graphics memory. TDP is 175 W-1 %. We recommend comparing the GPU with other models on our website to determine the best performance.

Specifications

Technical data
General info

Key features of the graphics card MSI Radeon RX 6650 XT GAMING X 8G.

  • Based on
    AMD Radeon RX 6650 XT
  • GPU Chip
    Navi 23 KXT (RDNA 2)
  • Execution units
    32
  • Shader
    2048
  • Render Output Units
    64
  • Texture Units
    128
  • Raytracing Cores
    32
no data
Memory settings

The characteristics of the video memory on board the graphics card. The higher the better.

  • Memory Size
    8 GB
  • Memory Type
    GDDR6
  • Memory Clock
    2.190 GHz
  • Memory Speed
    17.5 Gbps
  • Memory Bandwith
    280 GB/s
  • Memory Interface
    128 bit
no data
Clock frequency

Video card clock speed and overclocking potential MSI Radeon RX 6650 XT GAMING X 8G.

  • Base Clock
    2.055 GHz
  • Boost Clock
    2.694 GHz+ 2 %
  • Avg (Game) Clock
    2.523 GHz+ 5 %
  • Overclocking
    Yes
* see below
Thermal Management

Connectors, the number of thermal watts emitted in normal mode and at overclocking.

  • TDP
    175 W-1 %
  • TDP (up)
    --
  • Tjunction max
    --
  • PCIe-Power
    1 x 8-Pin
no data
Cooler & Fans type

Cooling system parameters, connectors and fan types MSI Radeon RX 6650 XT GAMING X 8G.

  • Fan-Type
    Axial
  • Fan 1
    2 x 100 mm
  • Fan 2
    --
  • Cooler-Type
    Air cooling
  • Noise (Idle)
    0 dB / Silent
  • Noise (Load)
    --
no data
Interfaces

Connectivity and connections.

  • Max. Displays
    4
  • HDCP-Version
    2.3
  • HDMI Ports
    1x HDMI v2.1
  • DP Ports
    3x DP v1.4a
  • DVI Ports
    --
  • VGA Ports
    --
  • USB-C Ports
    --
no data
Technical data

Hardware capabilities and maintaining the API.

  • Max. resolution
    7680x4320
  • DirectX
    12_2 (Ultimate)
  • Raytracing
    Yes
  • DLSS / FSR
    Yes
  • LED
    MSI Mystic Light
no data
Supported Video Codecs

Built-in support for video and image compression standards.

  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode / Encode
  • VP9
    Decode / Encode
  • AV1
    Decode
no data
Dimensions
  • Length
    278 mm
  • Height
    130 mm
  • Width
    51 mm
  • Width (Slots)
    3 PCIe-Slots
  • Weight
    894 g
no data
More information
  • GPU Interface
    PCIe 4.0 x 8
  • Release date
    Q2/2022
  • Release price
    --
  • Structure size
    7 nm
  • Part-no
    --
  • Documents
    data sheet
no data
Positions in all rankings

Common positions MSI Radeon RX 6650 XT GAMING X 8G GPU in popular benchmarks, for comparison with other models.

  • FP32 Performance (Single-precision TFLOPS)
    1237 place
  • Battlefield 5
    1378 place
  • Shadow of the Tomb Raider
    1461 place
  • Crypto-Mining Ethereum Hashrate (MH/s)
    2320 place
  • 3DMark Benchmark
    1160 place
  • Cyberpunk 2077
    37 place
  • GTA 5 Benchmark (Grand Theft Auto V)
    36 place

Benchmarks

Performance tests GPU

Compare the scores of popular benchmarks MSI Radeon RX 6650 XT GAMING X 8G with other graphics cards to understand the real speed of the GPU when processing content.

Tests include working with floating point, creating 3D models, mining cryptocurrencies.

FP32 Performance (Single-precision TFLOPS)
Benchmark FP32 is a 32-bit floating point calculation for the GPU which is required for 3D gaming
3DMark Benchmark
3DMark is designed for gamers, overclockers and system builders who want to get the most out of their hardware
10339
AMD Radeon RX 6700
10253
NVIDIA GeForce RTX 2070 SUPER
10219
10111
MSI Radeon RX 6650 XT GAMING X 8G
Cyberpunk 2077
In Cyberpunk 2077 there is a built-in benchmark, which allows you to check the compliance of your computer requirements for the game
30 fps (avg)
MSI Radeon RX 6650 XT GAMING X 8G
30 fps (avg)
NVIDIA GeForce RTX 3060
30 fps (avg)
NVIDIA GeForce RTX 3060 LHR
30 fps (avg)
Battlefield 5
Battlefield 5 is a realistic game, with a built-in benchmark, very suitable as a test for graphics cards
56 fps (avg)
55 fps (avg)
NVIDIA GeForce RTX 2070 SUPER
55 fps (avg)
MSI Radeon RX 6650 XT GAMING X 8G
55 fps (avg)
NVIDIA GeForce RTX 3060
Shadow of the Tomb Raider
Shadow of the Tomb Raider has a built-in benchmark, based on the Crystal Dynamics Foundation engine
38 fps (avg)
NVIDIA GeForce RTX 3070 Mobile (Laptop GPU)
38 fps (avg)
37 fps (avg)
MSI Radeon RX 6650 XT GAMING X 8G
37 fps (avg)
GTA 5 Benchmark (Grand Theft Auto V)
The benchmark is based on Rockstar North's RAGE Engine
62 fps (avg)
NVIDIA GeForce RTX 3060 Ti GDDR6X
62 fps (avg)
AMD Radeon RX 6700
61 fps (avg)
MSI Radeon RX 6650 XT GAMING X 8G
61 fps (avg)
Crypto-Mining Ethereum Hashrate (MH/s)
Ethash is an algorithm for mining Ethereum cryptocurrency that makes the most of the GPU
27 MH/s
26 MH/s
NVIDIA GeForce RTX 3050 Ti Mobile (Laptop GPU)
26 MH/s
MSI Radeon RX 6650 XT GAMING X 8G
26 MH/s

Synonyms

Similar graphics cards in terms of performance.

Similar in technical data GPU with MSI Radeon RX 6650 XT GAMING X 8G.

XFX Speedster MERC 308 Radeon RX 6650 XT BLACK Gaming View
EVGA GeForce RTX 2080 SUPER Gaming View
EVGA GeForce RTX 2080 SUPER XC2 GAMING View
XFX Speedster QICK 308 Radeon RX 6650 XT Ultra Gaming View
ZOTAC GAMING GeForce RTX 2080 AMP View
MANLI GeForce RTX 2080 SUPER Gallardo with customized LED Lights (M3442+N502-00) View
EVGA GeForce RTX 2080 SUPER FTW3 View
ZOTAC Gaming GeForce RTX 2080 SUPER Twin Fan View

*

Base Clock - this is the guaranteed speed that the manufacturer sets for the type of cooling and binning that the GPU comes out of the factory with.

Boost Clock - this is a theoretical minimum speed to which the video card can be overclocked considering the cooling and binning requirements.
