Intel Core i5-1035G7

Processor Intel Core i5-1035G7, specifications and benchmarks

531 place in the overall ranking CPUs!
Intel Core i5-1035G7 Processor is being reviewed, the release of which was held in Q3/2019. Here are all the Intel Core i5-1035G7’s specifications and performance estimation in benchmark. We offer to study all the data and compare it with a competing model. The base clock frequency of the model is 1.20 GHz, total of cores is 4. The CPU supports DDR4-3200LPDDR4-3733 and is installed in the motherboard on Socket BGA 1526. The TDP for CPU is 15 W.

Specifications

Technical data
CPU family and group

General information about the processor Intel Core i5-1035G7

  • Segment
    Mobile
  • Family
  • Generation
    10
  • CPU group
    Intel Core i 1000G/10000U
  • Predecessor
    --
  • Successor
    --
CPU Technical specs

Intel Core i5-1035G7 Processor performance parameters, CPU capabilities

  • Frequency
    1.20 GHz
  • CPU Cores
    4
  • Turbo (1 Core)
    3.70 GHz
  • CPU Threads
    8
  • Turbo (4 Cores)
    3.30 GHz
  • Hyperthreading
    Yes
  • Overclocking
    No
  • Core architecture
    normal
  • A core
    --
  • B core
    --
  • C core
    --
IGPU

Built-in graphics chip characteristics

  • GPU name
    Intel Iris Plus Graphics (Ice Lake G7)
  • GPU frequency
    0.30 GHz
  • GPU (Turbo)
    1.05 GHz
  • Execution units
    64
  • Shader
    512
  • Max. GPU Memory
    --
  • Max. displays
    3
  • Generation
    11
  • DirectX Version
    12
  • Technology
    14 nm
  • Release date
    Q3/2019
Hardware codec support

Built-in support for video and image compression standards

  • h265 / HEVC (8 bit)
    Decode / Encode
  • h265 / HEVC (10 bit)
    Decode / Encode
  • h264
    Decode / Encode
  • VP9
    Decode / Encode
  • VP8
    Decode / Encode
  • AV1
    No
  • AVC
    Decode / Encode
  • VC-1
    Decode
  • JPEG
    Decode / Encode
Memory specs & PCI

Technical characteristics of supported memory, PCI bus

  • Memory type
    DDR4-3200LPDDR4-3733
  • Max. Memory
    64 GB
  • ECC
    No
  • Memory channels
    2
  • PCIe version
    3.0
  • PCIe lanes
    16
Encryption

Hardware security technology

  • AES-NI
    Yes
Thermal Management
  • TDP (PL1)
    15 W
  • TDP up
    25 W
  • TDP (PL2)
    --
  • TDP down
    12 W
  • Tjunction max.
    100 °C
* see below
Technologies and extensions

Technical capabilities of the processor, information

  • Instruction set (ISA)
    x86-64 (64 bit)
  • Virtualization
    VT-x, VT-x EPT, VT-d
  • ISA extensions
    SSE4.1, SSE4.2, AVX2
  • L2-Cache
    --
  • L3-Cache
    6.00 MB
  • Architecture
    Ice Lake U
  • Technology
    10 nm
  • Socket
    BGA 1526
  • Release date
    Q3/2019
  • Part Number
    --
Positions in all rankings

Common positions Intel Core i5-1035G7 CPU in popular benchmarks, for comparison with other models.

  • Cinebench R23 (Single-Core)
    245 place
  • Cinebench R23 (Multi-Core)
    270 place
  • Cinebench R20 (Single-Core)
    261 place
  • Cinebench R20 (Multi-Core)
    318 place
  • Cinebench R15 (Single-Core)
    259 place
  • Cinebench R15 (Multi-Core)
    455 place
  • iGPU - FP32 Performance (Single-precision GFLOPS)
    246 place
  • Estimated results for PassMark CPU Mark
    410 place

Benchmarks

Performance tests CPU

Compare the scores of popular benchmarks Intel Core i5-1035G7 with other processors to understand the real speed of the CPU when processing content.

Tests include mathematical calculations, creation of 3D models, cryptocurrency mining, tests in single and multi-core modes.

Cinebench R23 (Single-Core)
Maxon's Cinebench R23 SC is a cross-platform test suite for macOs and Windows uses one CPU core, with no hypetrading
Cinebench R23 (Multi-Core)
Maxon's Cinebench R23 MC is a cross-platform test suite for macOs and Windows using a multi-core and hyperthreading
4539
4475
4436
4430
Intel Core i5-1035G7
Cinebench R20 (Single-Core)
Cinebench R20 SC is a high load CPU test for long tasks on a desktop or notebook PC, uses one CPU core, with no hypetrading
437
437
437
434
Intel Core i5-1035G7
Cinebench R20 (Multi-Core)
Cinebench R20 MC is a high load CPU test for long tasks on a desktop or notebook PC, using a multi-core and hyperthreading
1630
1630
1628
1595
Intel Core i5-1035G7
Cinebench R15 (Single-Core)
The Cinebench R15 SC stresses the computing modules of a desktop or laptop computer to their limits and accurately determines the key performance parameters of the hardware
Cinebench R15 (Multi-Core)
The Cinebench R15 MC stresses the computing modules of a desktop or laptop computer to their limits and accurately determines the key performance parameters of the hardware
665
665
665
664
Intel Core i5-1035G7
iGPU - FP32 Performance (Single-precision GFLOPS)
The performance of the iGPU - the internal GPU in games
1126
1106
1094
1075
Intel Core i5-1035G7
Estimated results for PassMark CPU Mark
PassMark is a test suite that performs complex mathematical calculations to determine CPU performance on file compression, encryption and physics-related tasks
9538
9520
9520
9511
Intel Core i5-1035G7

Synonyms

Similar processors in terms of performance.

Similar in technical data processors with Intel Core i5-1035G7.

Intel Xeon E3-1515M v5 View
Intel Xeon W-2133 View
Intel Core i5-7600 View
Intel Core i5-10300H View
Intel Xeon E3-1245 v5 View
Intel Xeon E5-1660 v4 View
Intel Xeon E5-2640 v4 View
Intel Xeon E5-2658 v3 View

*

PL1 - Amount of heat in watts generated by the processor (or GPU) during normal operation.

PL2 - on overclocking

The values are used to select the optimal cooling system and power supply.
