AMD Ryzen 9 5900XT vs AMD Ryzen 5 5500F. Specifications

Background information about the processors being compared, series, generation and market segment.

• Family
  Ryzen Ryzen
• Form Factor
  Boxed Processor / Desktops Desktops / Boxed Processor
• Segment
  Desktop Desktop
• Series
  Ryzen 5000 Series Ryzen 5000 Series

Core counts, threads, cache and clock modes describe the CPU configuration. Performance depends on the workload and comparable measured results.

• Base Frequency
  3.3 GHz 3 GHz
• CPU Cores
  16 6
• CPU Threads
  32 12
• Max. Boost Clock
  4.8 GHz 4.4 GHz
• Overclocking
  Yes Yes

Internal Graphics does not affect the performance of the CPU, performs the work of the graphics card in its absence or on mobile devices.

• GPU name
  None None

Types, channel quantity of RAM supported by AMD Ryzen 5 5500F and AMD Ryzen 9 5900XT. Depending on the motherboards, higher or lower memory frequencies may be supported.

• Memory channels
  2 2
• Memory type
  DDR4 DDR4
• PCIe
  PCIe 4.0 PCIe 4.0
• System Memory Specification
  - 3200

Compare the TDP requirements of TDP AMD Ryzen 9 5900XT and AMD Ryzen 5 5500F Power specifications describe different manufacturer limits. TDP, base power and maximum turbo power are separate values; they do not establish measured system consumption.

• Default TDP
  105 W 65 W
• Maximum Operating Temperature
  90 °C 95 °C

Architecture, interfaces, additional instructions supported by AMD Ryzen 9 5900XT and AMD Ryzen 5 5500F, virtual machine technologies and process technology.

• Codename
  Vermeer Vermeer
• L2-Cache
  8 MB 3 MB
• L3-Cache
  64 MB 16 MB
• Official source
  https://www.amd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-9-5900xt.html https://www.amd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-5-5500f.html
• Release date
  2024-07-31 2026-09-10
• Socket
  AM4 AM4
• Technology
  TSMC 7nm FinFET TSMC 7nm FinFET
• Verified on
  2026-09-30 2026-09-30
