ASUS ROG Strix GeForce GTX 1650 OC
ビデオカード2の選択
User rating
star star star star star
発売済み
Q2/2019
ASUS ROG Strix GeForce GTX 1650 OC

グラフィックカード ASUS ROG Strix GeForce GTX 1650 OC, 仕様とベンチマーク

2656 総合ランキング1位 グラフィックスカード (GPU)!
製造開始日がQ2/2019のASUS ROG Strix GeForce GTX 1650 OCの詳細レビューです。ここでは、すべての仕様と、最新のベンチマークによる推定性能の結果を紹介します。ベースクロック周波数は1.485 GHzです。GPUはGDDR5をサポートし、4 GBのグラフィックメモリを搭載しています。TDPは75 Wです。GPUの性能については、弊社ホームページの他モデルと比較されることをお勧めします。

仕様

技術データ
GPU
  • に基づいています。
    NVIDIA GeForce GTX 1650 (GDDR5)
  • Execution Units
    14
  • GPUチップ
    TU117-300-A1
  • レンダリング出力単位
    32
  • シェーダー
    896
  • テクスチャユニット
    56
メモリ
  • Memory Bandwidth
    128 GB/s
  • Memory Bus
    128 bit
  • メモリサイズ
    4 GB
  • Memory Speed (legacy frequency label)
    2000 MHz
  • メモリータイプ
    GDDR5
クロック周波数
  • 基本周波数
    1485 MHz
  • 最大周波数
    1860 MHz + 12%
  • Game Clock
    1830 MHz
  • オーバークロッキング
    はい
エネルギー消費量
  • Maximum Junction Temperature
    —
  • TDP
    75 W
  • TDP (up)
    —
冷却
  • クーラータイプ
    Air cooling
  • ファンタイプ
    Axial
  • ファン1
    2 x 100 mm
  • ファン2
    —
  • Noise (Idle)
    —
  • Noise (Load)
    —
コネクティビティ
  • DisplayPort Ports
    2 × DisplayPort 1.4
  • DVIポート
    —
  • HDCP Version
    2.2
  • HDMI端子
    2 × HDMI 2.0b
  • Max. 表示数
    3
  • PCIe Interface
    PCIe 3.0 x16
  • Power Connectors
    1 x 6-Pin
  • USB-C Ports
    —
  • VGA Ports
    —
フィーチャーセット
  • DirectX
    12_1
  • DLSS / FSR
    いいえ
  • LED
    Non addressable LED
  • 最大解像度
    3840 × 2160
  • レイトレーシング
    いいえ
対応するビデオコーデック
  • AV1
    いいえ
  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode
  • VP9
    Decode
外形寸法図
  • 高さ
    127 mm
  • 長さ
    242 mm
  • Slot Size
    2 PCIe-Slots
  • Weight
    —
  • Width
    38 mm
追加データ
  • スペック
    data sheet
  • Launch Price (historical)
    —
  • Part Number
    ROG-STRIX-GTX1650-O4G-GAMING
  • Process Technology
    12 nm
  • 発売日
    Q2/2019
全ランキングでの順位

共通ポジション ASUS ROG Strix GeForce GTX 1650 OC 他機種との比較のため、一般的なベンチマークでGPUを使用。.

  • FP32 Performance (Single-precision TFLOPS)
    2853 place
  • Battlefield 5
    2749 place
  • Shadow of the Tomb Raider
    2662 place
  • Crypto-Mining Ergo Hashrate (MH/s)
    2761 place
  • Crypto-Mining Ravencoin Hashrate (MH/s)
    2478 place

ベンチマーク

性能試験 GPU

一般的なベンチマークのスコアを比較する ASUS ROG Strix GeForce GTX 1650 OC 他のグラフィックスカードとの比較により、コンテンツ処理時のGPUの実速度を把握することができます.

テスト内容は、浮動小数点演算、3Dモデルの作成、暗号通貨の採掘などです.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archive: saved catalog source links. The original measurement method and test conditions have not been verified; current source pages may differ from the imported content. ASUS ROG Strix GeForce GTX 1650 OC

FP32 Performance (Single-precision TFLOPS)
ベンチマークFP32は、3Dゲームに必要なGPUの32ビット浮動小数点演算です.

Higher values are better in this metric.

3.33 TFLOPS
ASUS ROG Strix GeForce GTX 1650 OC
3.94 TFLOPS
3.36 TFLOPS
3.33 TFLOPS
Battlefield 5
バトルフィールド5」はリアルなゲームであり、ベンチマークを内蔵しているので、グラフィックカードのテストとして非常に適している.

Higher values are better in this metric.

Shadow of the Tomb Raider
シャドウ オブ ザ トゥームレイダー』には、Crystal Dynamics Foundation製エンジンをベースにしたベンチマークが内蔵されています.

Higher values are better in this metric.

Crypto-Mining Ergo Hashrate (MH/s)
Ergo暗号のベースとなっているAutolykosアルゴリズムは、最新のGPUだけでなく、過去の世代のGPUもマイニングに使用することが可能です.

Higher values are better in this metric.

Crypto-Mining Ravencoin Hashrate (MH/s)
KawPoWアルゴリズムでRavencoin暗号通貨を採掘するハッシュレートは、最新のビデオカードで最速となる.

Higher values are better in this metric.

同義語

Nearby models in the composite benchmark index.

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted. Index 0–100: equal-weight mean of each score relative to the best saved score among models with both tests. Tests: Battlefield 5 + Shadow of the Tomb Raider. This index does not predict performance in every workload.

Recent models: test results with identified primary sources — Game frame rates

Colorful iGame GeForce GTX 1650 Ultra 4G-V Colorful iGame GeForce GTX 1650 Ultra 4G-V 表示
EVGA GeForce GTX 1650 SC ULTRA GAMING EVGA GeForce GTX 1650 SC ULTRA GAMING 表示
EVGA GeForce GTX 1650 XC OC EVGA GeForce GTX 1650 XC OC 表示
Gigabyte GeForce GTX 1650 GAMING OC 4G Gigabyte GeForce GTX 1650 GAMING OC 4G 表示
EVGA GeForce GTX 1650 XC ULTRA OC EVGA GeForce GTX 1650 XC ULTRA OC 表示
Palit GeForce GTX 1060 GamingPro OC+ Palit GeForce GTX 1060 GamingPro OC+ 表示
INNO3D GeForce GTX 1060 Gaming OC V3 GDDR5X INNO3D GeForce GTX 1060 Gaming OC V3 GDDR5X 表示
INNO3D GeForce GTX 1060 Gaming OC GDDR5X INNO3D GeForce GTX 1060 Gaming OC GDDR5X 表示

*

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.
