Gainward GeForce RTX 3090 Phantom+
비디오 카드 선택 2
User rating
star star star star star
출시
Q3/2020
Gainward GeForce RTX 3090 Phantom+

그래픽 카드 Gainward GeForce RTX 3090 Phantom+, 사양 및 벤치마크

에 대한 상세 리뷰입니다 Gainward GeForce RTX 3090 Phantom+, 제조 날짜는 Q3/2020에서 시작되었습니다. 다음은 모든 사양과 최신 벤치마크 추정치의 성능 결과입니다. 기본 클럭 주파수는 1.395 GHz입니다. GPU는 GDDR6X 그래픽 메모리와 24 GB 그래픽 메모리를 지원합니다. TDP is 370 W+ 6 %. 웹 사이트에서 다른 모델과 GPU를 비교하여 최상의 성능을 확인할 것을 권장합니다.

사양

기술 데이터
GPU
  • 기준
    NVIDIA GeForce RTX 3090
  • Execution Units
    82
  • GPU 칩
    GA102-300-A1
  • 렌더링 출력 유닛 (ROP)
    112
  • Shader
    10496
  • 텍스처 단위 (TMU)
    328
메모리
  • Memory Bandwidth
    936 GB/s
  • Memory Bus
    384 bit
  • 메모리 크기
    24 GB
  • Memory Speed (legacy frequency label)
    1219 MHz
  • 메모리 유형
    GDDR6X
클럭 속도
  • 기본 시계
    1395 MHz
  • 부스트 클럭
    1740 MHz + 3%
  • Game Clock
    —
  • 오버클러킹
    예
열 설계
  • Maximum Junction Temperature
    93 °C
  • TDP
    370 W+ 6 %
  • TDP (up)
    —
쿨러 및 팬
  • 쿨러 유형
    Air cooling
  • 팬 유형
    Axial
  • 팬 1
    3 x 90 mm
  • 팬 2
    —
  • Noise (Idle)
    0 dB / Silent
  • Noise (Load)
    —
연결성
  • DisplayPort Ports
    3 × DisplayPort 1.4a
  • DVI 포트
    —
  • HDCP Version
    2.3
  • HDMI 포트
    1 × HDMI 2.1
  • 최대. 디스플레이
    4
  • PCIe Interface
    PCIe 4.0 x16
  • Power Connectors
    3 x 8-Pin
  • USB-C Ports
    —
  • VGA Ports
    —
기능 세트
  • DirectX
    12_2
  • DLSS / FSR
    예
  • LED
    Addressable LED
  • 최대 해상도
    7680 × 4320
  • 레이 트레이싱
    예
지원되는 비디오 코덱
  • AV1
    Decode
  • h264
    Decode / Encode
  • h265 / HEVC
    Decode / Encode
  • VP8
    Decode
  • VP9
    Decode
치수
  • 높이
    136 mm
  • 길이
    304 mm
  • Slot Size
    3 PCIe-Slots
  • Weight
    —
  • Width
    —
추가 데이터
  • 문서
    data sheet
  • Launch Price (historical)
    1,629 $
  • Part Number
    NED3090019SB-1021P
  • Process Technology
    8 nm
  • 릴리스 날짜
    Q3/2020
모든 순위의 순위

공통 위치 Gainward GeForce RTX 3090 Phantom+ 다른 모델과의 비교를 위한 인기 벤치마크의 GPU.

  • 3DMark Benchmark
    95 place
  • Crypto-Mining Ravencoin Hashrate (MH/s)
    198 place

Manufacturer versions

Board specifications and benchmark results are specific to each version.

All models based on this GPU

벤치마크

성능 테스트 GPU

인기 벤치마크 점수 비교하기 Gainward GeForce RTX 3090 Phantom+ 다른 그래픽 카드와 함께 사용하여 콘텐츠 처리 시 GPU의 실제 속도를 파악할 수 있습니다..

테스트에는 부동 소수점 작업, 3D 모델 생성, 암호화폐 채굴이 포함됩니다..

These are saved results from the earlier catalog. Measurement dates and test configurations were not recorded. Models with no comparable results are omitted.

Recent models: test results with identified primary sources — Game frame rates

Archive: saved catalog source links. The original measurement method and test conditions have not been verified; current source pages may differ from the imported content. Gainward GeForce RTX 3090 Phantom+

3DMark Benchmark
3DMark는 하드웨어를 최대한 활용하고자 하는 게이머, 오버클러커 및 시스템 빌더를 위해 설계되었습니다.

Higher values are better in this metric.

Crypto-Mining Ravencoin Hashrate (MH/s)
최신 비디오 카드에서 가장 빠른 해시레이트 마이닝 Ravencoin 암호 화폐는 KawPoW 알고리즘을 사용합니다.

Higher values are better in this metric.

45 MH/s
Gainward GeForce RTX 3090 Phantom+
46 MH/s
46 MH/s
45 MH/s

Comparable benchmark results are required to suggest performance alternatives.

*

Base Clock is the base GPU frequency stated by the manufacturer for this model.

Boost Clock describes automatic frequency increases. Actual clock speed varies with workload, temperature and power limits; it is not a guarantee of manual overclocking.
